| Brand: | MITSUBISHI | Modenl Number: | AJ65SBT2B-64AD |
|---|---|---|---|
| Country Of Origin: | Japan | Program Capacity: | 8 K Steps |
| Basic Operation Processing Speed (LD Instruction): | 0.12 μs | Input: | 100 To 240 V AC |
| Output: | 12VDC (0.5A) | Type: | Redundant Power Supply Module |
| Highlight: | analog interface module,plc power supply module |
||
AJ65SBT2B-64AD Mitsubishi Universal model Redundant Power Supply Module
AJ65SBT2B-64AD Overview
The AJ65SBT2B-64AD is a high-performance 4-channel analog input module manufactured by Mitsubishi Electric, designed for industrial automation systems. It integrates with CC-Link networks to facilitate precise data acquisition from sensors and transducers, converting analog signals (e.g., temperature, pressure) into digital values for PLC processing. This module is widely used in applications such as production line monitoring, environmental parameter collection, and energy management systems
.
High Precision and Resolution
Supports voltage inputs (±10 V DC) and current inputs (0–20 mA DC) with a resolution of 1/16,000 (e.g., 0.625 mV for ±10 V range).
Accuracy of ±0.2% (at 25°C ±5°C) ensures reliable data conversion for critical industrial processes
.
Fast Conversion Speed
Processes data at 200 µs per channel, enabling real-time monitoring and control in high-speed automation environments
.
Robust Design and Compatibility
Compatible with CC-Link networks as a remote device station (occupies 1 station).
Features photocoupler and transformer isolation between communication, power, and analog input systems, enhancing noise resistance and safety in harsh environments
.
Flexible Configuration
Supports user-defined input ranges (e.g., -10–10 V, 0–20 mA) and offers multiple resolution modes (e.g., 0–16,000 or ±16,000 digital output)
.
Easy Integration
Utilizes a two-piece terminal block (M3 screws) for straightforward wiring and maintenance
.
Material: Constructed with industrial-grade components, including reinforced plastic housing and metal connectors, ensuring durability and EMI shielding.
Primary Applications:
Industrial Automation: Multi-point monitoring of temperature, pressure, and flow in manufacturing equipment (e.g., injection molding machines).
Building Management: Collecting environmental data (e.g., humidity, airflow) in HVAC systems.
Energy and Utilities: Monitoring electrical parameters (voltage, current) in power distribution systems
.
|
Parameter |
Specification |
|---|---|
| Input Channels | 4 channels |
| Input Types | Voltage: ±10 V DC; Current: 0–20 mA DC |
| Resolution | 1/16,000 (e.g., 0.625 mV for ±10 V range) |
| Conversion Speed | 200 µs per channel |
| Accuracy | ±0.2% (at 25°C ±5°C); ±0.3% (at 0–55°C) |
| Isolation | Photocoupler isolation (communication/analog), transformer isolation (power) |
| Power Supply | DC 24 V (20.4–28.8 V), 0.12 A consumption |
| Occupied CC-Link Stations | 1 station |
| External Connection | Two-piece terminal block (M3 screws) |
| Weight | 0.25 kg |
Data sourced from Mitsubishi Electric specifications
.
The module complies with international standards including UL, cUL, CE (EMC/RoHS), and KC(EMC)
.
For detailed wiring diagrams and programming examples, refer to the official Mitsubishi user manual (available in Chinese and English)
.
|
