AJ65SBTB32-16KDR Mitsubishi Universal Model Redundant Power Supply Module

: Large Image : AJ65SBTB32-16KDR Mitsubishi Universal Model Redundant Power Supply Module

Product Details:

Place of Origin:	Japan
Brand Name:	MITSUBISHI
Certification:	CE
Model Number:	AJ65SBTB32-16KDR

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Contact
Packaging Details:	new and original
Delivery Time:	5-7 days
Payment Terms:	T/T, Western Union,paypal
Supply Ability:	100

Contact Now

Detailed Product Description

Brand:	MITSUBISHI	Modenl Number:	AJ65SBTB32-16KDR
Country Of Origin:	Japan	Program Capacity:	8 K Steps
Basic Operation Processing Speed (LD Instruction):	0.12 μs	Input:	100 To 240 V AC
Output:	5 V DC/3 A	Type:	Redundant Power Supply Module
Highlight:	analog interface module , plc power supply module

AJ65SBTB32-16KDR Mitsubishi Universal model Redundant Power Supply Module

AJ65SBTB32-16KDR Overview

The AJ65SBTB32-16KDR is a DC input/relay output module designed by Mitsubishi Electric for CC-Link industrial networks. It integrates 16 DC input points and 16 relay output points, enabling seamless data acquisition and control in automated systems. This module acts as a remote I/O station, facilitating communication between PLCs and field devices (e.g., sensors, actuators) while reducing wiring complexity. It is widely used in manufacturing, energy management, and process control applications where reliability and noise immunity are critical

AJ65SBTB32-16KDR Key Features

1.
High Compatibility and Flexibility
- •
  Supports CC-Link network integration (occupies 1–2 stations, depending on configuration) and operates with DC 24V input (7mA per point) and relay output (AC/DC compatible)
  .
- •
  Allows mixed signal handling (e.g., digital inputs with relay-driven outputs) for diverse industrial scenarios
  .
2.
Robust Isolation and Durability
- •
  Features photocoupler isolation for inputs and relay isolation for outputs, ensuring protection against electrical noise and voltage surges
  .
- •
  Withstands harsh environments with an operating temperature range of 0–55°C and compliance with IP1X protection standards
  .
3.
Fast Response and Precision
- •
  Input response time: 1.5 ms (at DC 24V); output response: OFF→ON ≤10 ms, ON→OFF ≤12 ms
  .
- •
  High accuracy with ON voltage ≥14V / ON current ≥3.5mA and OFF voltage ≤6V / OFF current ≤1.7mA
  .
4.
Efficient Wiring and Installation
- •
  Uses 34-point direct-mount terminal blocks (M3 screws) for simplified wiring and maintenance
  .
- •
  Compact dimensions (50 × 179 × 40 mm) and lightweight design (0.28 kg) for space-saving integration
  .
5.
Redundant and Scalable Design
- •
  Supports dual-loop configurations and network expansion via CC-Link, enabling scalable automation architectures
  .

AJ65SBTB32-16KDR Material and Applications

•
Material: Constructed with industrial-grade components, including reinforced plastic housing, metal terminals, and optical/relay isolation elements for EMI shielding and mechanical durability
.
•
Primary Applications:
- •
  Factory Automation: Control of conveyor systems, robotic arms, and packaging machinery.
- •
  Energy Systems: Monitoring and switching in power distribution units.
- •
  Building Management: HVAC control and lighting system automation
  .

AJ65SBTB32-16KDR Technical Parameters

Parameter	Specification
Input Channels	16 points
Input Type	DC 24V (7 mA per point); positive/negative common shared
Input Response Time	≤1.5 ms
Output Channels	16 points (relay output)
Output Rating	DC 24V 2A/point; AC 240V 2A/point; 4A per common terminal
Output Response Time	OFF→ON ≤10 ms; ON→OFF ≤12 ms
Isolation	Photocoupler isolation (inputs); relay isolation (outputs)
Power Supply	DC 20.4–26.4 V; 85 mA consumption (all points ON)
External Connection	34-point terminal block (M3 screws)
Occupied CC-Link Stations	1–2 stations (configurable)
Weight	0.28 kg
Dimensions (H × W × D)	50 × 179 × 40 mm

Data sourced from Mitsubishi Electric specifications

Model: AJ65SBTB32-16KDR
Input AJ65SBTB32-16KDR 8 points: 24VDC (positive/negative AJ65SBTB32-16KDR common shared) .
3-wire type.
Response time 0.2/1.5/5/10ms .
switching type.
Output 8 points: 24VDC/240VAC (2A) .
Relay output .
2-wire type.
Terminal block type.
Screw terminal block type

Mitsubishi AJ65SBTB32-16KDR

Model: AJ65SBTB32-16KDT8
Input 8 points: 24VDC (positive common).
3-wire MITSUBISHI AJ65SBTB32-16KDR type.
Response time 0.2/1.5/5/10ms.
switching type
Output 8 points: 12VDC (0.5A).
Transistor MITSUBISHI AJ65SBTB32-16KDR output (sink type).
2-wire type .
Terminal block type (low-leakage current MITSUBISHI AJ65SBTB32-16KDR type).
Screw terminal block type

Model: AJ65SBTB32-16DT2
Input 8 points: 24VDC (positive common).
3-wire type.
Response time 1.5ms.
Output 8 points: 24VDC (0.5A).
Transistor output (sink type) .
2-wire type.
Terminal block type (low-leakage current type).
Screw terminal block type

Model: AJ65SBTB32-16DT
Input 8 points: 24VDC (positive common).
3-wire type.
Response time 1.5ms.
Output 8 points: 24VDC (0.5A).
Transistor output(sink type).
2-wire type.
Terminal block type.
Screw terminal block type

Model: AJ65SBTB32-16KDT2
Input 8 points: 24VDC (positive common).
3-wire type.
Response time 0.2/1.5/5/10ms.
switching type
Output 8 points: 24VDC (0.5A).
Transistor output (sink type) .
2-wire type .
Terminal block type (loww-leakage AJ65SBTB32-16KDR current type).
Screw terminal block type
