Product Details:
Payment & Shipping Terms:
|
| Range Of Product: | Modicon Quantum Automation Platform | Product Or Component Type: | Analogue Input Module |
|---|---|---|---|
| Software Designation: | Concept >= V2.0 ProWORX 32 NxT V2.0 | Country Of Origin: | France |
| PN: | 140CHS11000 | Condition: | Original And New |
| Deliver: | 3days | Warranty: | 1 Year |
| High Light: | quantum unity processor,modicon quantum cpu |
||
Quick details:
| RFI immunity |
27...1000 MHz 9.14 V/yd (10 V/m) conforming to IEC 60801-3
|
|
|---|---|---|
| resistance to electrostatic discharge |
4 kV contact
8 kV air |
|
| ambient air temperature for operation |
32...140 °F (0...60 °C)
|
|
| ambient air temperature for storage |
-40...185 °F (-40...85 °C)
|
|
| relative humidity |
95 % without condensation
|
|
| operating altitude |
<= 16404.2 ft (5000 m)
|
| Category |
18150 - QUANTUM CONTROLLERS,HSBY,COMM.
|
|
|---|---|---|
| Discount Schedule |
PC21
|
|
| GTIN |
00785901104339
|
|
| Nbr. of units in pkg. |
1
|
|
| Package weight(Lbs) |
2.21
|
|
| Returnability |
N
|
|
| Country of origin |
FR
|
(1) 2 slots
(2) 3 slots
(3) 4 slots
(4) 6 slots
(5) 10 slots
(6) 16 slots
Legacy KB System (APS) Data: RESL197850 V2.0, Originally authored by DiSa on 02/18/2009, Last Edited by DiSa on 11/15/2012
Related ranges: Modicon Quantum
This resolution describes a workaround for an effect by a Hot Standby switchover with RIO and a software counter.
The RIO cable connection to the Primary CRP 931 fails.
An input from a 140 DDI 353 00 module has value "1" at the same time.
The Standby system switches to Primary (what is correct).
But the input bit gets for a short time the value "0", because the CRA is not available while switchover.
If the binary input is linked to a software counter the counter will change the value. Also affected are program parts, which use this binary input together with Edge detection.
Problem is known with the following components:
Concept 2.6 SR2
140CPU43412A, EXEC 1.25, Kernel 1.01
140CHS11000, EXEC 1.04, Kernel 1.00
140CRP93100, EXEC 1.15, Kernel 1.01
140 DDI 353 00
It should exist with all Hot Standby systems equiped with 140CRP93100, every discrete Input and a software counter or a Edge detection is linked to the Input module.
Use the EN input of the software counter and link it to the healthy bit of the Input module. This avoids to increase the counter during RIO cable interrupt.
