RS-232C Connector Modicon Quantum PLC Controls 140CHS41010 CE Certificated

Superb delivery a great product, perfect communication as well !! A++++

—— Carlos

Great deal. Fast shipping and good service.Recommended !!!!!!!!!

—— Gita

I'm Online Chat Now

RS-232C Connector Modicon Quantum PLC Controls 140CHS41010 CE Certificated

Large Image :  RS-232C Connector Modicon Quantum PLC Controls 140CHS41010 CE Certificated

Product Details:

Place of Origin: France
Brand Name: Schneider
Certification: CE
Model Number: 140CHS41010

Payment & Shipping Terms:

Minimum Order Quantity: 1PC
Price: 1-1000USD/pc
Packaging Details: new original package
Delivery Time: 2-3 working days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 10 pcs/month
Detailed Product Description
Range Of Product: Modicon Quantum Automation Platform Kit Type: Hot Standby Kit
Country Of Origin: France PN: 140CHS41010
Condition: Original And New Brand: Schneider
MOQ: 1 PIECE Warranty: 1 Year
High Light:

modicon quantum processor

,

modicon quantum cpu





Schneider Electric Modicon Quantum PLC 140CHS41010 NEW FACTORY SEALED









Quick details:





  • SCHNEIDER ELECTRIC
  • MODICON
  • 140-CHS-410-10
  • 140CHS41010
  • LEVEL ONE LOW COST HOT STANDBY KIT
  • AVAILABLE
  • New one with one year warranty and used one with six months warranty
  • Weight: 5.59lbs









More Info on the 140CHS41010:







See Quantum 140-CHS-410-10 PDF below for product info.

Quantum | 140CHS41010 | Modicon | 140 CHS 410 10 | Hot Standby L1 Kit

The MSX modules are equipped with a 9-pin, RS-232C connector that supports Modicon’s proprietary Modbus communication protocol. The following is the Modbus port pinout connections for 9-pin and 25-pin connections.













Complementary:





kit type
Hot Standby kit

kit composition
1 S908 terminator kit
1 installation manual
1 CHS loadable software package
1 fiber optic (3m) hot standby cable
2 140CPU11302 Quantum CPUs
2 140CRP93101 remote I/O processors
2 140CHS11000 hot standby processors
2 140XBP00600 backplanes
2 140CPS11100 power supplies






Ordering and shipping details:





Category
18150 - QUANTUM CONTROLLERS,HSBY,COMM.

Discount Schedule
PC21

GTIN
00785901761297

Nbr. of units in pkg.
1

Package weight(Lbs)
22.050000000000001

Returnability
N

Country of origin
FR










Offer Sustainability:





Sustainable offer status
Green Premium product

RoHS (date code: YYWW)
Compliant - since 1045 - Schneider Electric declaration of conformity Schneider Electric declaration of conformity

REACh
Product environmental profile
Available

Product end of life instructions
Available





ConneXium™ managed switches (continued) Predefined configuration files (continued) Example topology with predefined configuration files C5, C1 and C3 (1) A common use of this preconfiguration is for interfacing a copper link with a fiber optic link on the primary ring or interfacing a fiber optic link with a copper link. This type of architecture makes it possible to have Ethernet DIO or Ethernet RIO drops some distance away from the PLC. The switch preconfiguration also enables Ethernet RIO and/or several Ethernet DIO device clouds to be connected to a secondary ring.









1  Primary ring, copper/fiber optic medium

2  Ethernet DIO secondary ring, copper medium only

3  Ethernet head adaptor 140CRP31200 installed in the Quantum™ rack.

4  ConneXium switch TCSESM083F23F1 with predefined configuration file C2 (2)

5  ConneXium switch TCSESM063F2CU1/CS1 with predefined configuration file C6 (2)

6  ConneXium switch TCSESM063F2CU1/CS1 with predefined configuration file C4 (2)

7  Modicon™ STB Ethernet DIO (3) (4)

8  Connection to Ethernet DIO device cloud, copper medium only

9  Ethernet DIO device cloud (3)

10  Ethernet communication module 140NOE771

11  Ethernet Interlink cable TCSECN3M3M1S4/1S4U (1 m)







Technical FAQs:











Is there a fiber optic distance requirement between the 140CHS11000 modules in a Quantum Hot Standby System?







The fiber optic distance requirement between the 140CHS11000 modules is 3 meters which is the length of the supplied fiber cable.
A maximum distance can be up to 1km using 62.5/125 micrometer fiber cable with ST style connectors.



Legacy KB System (APS) Data: RESL197850 V2.0, Originally authored by DiSa on 02/18/2009, Last Edited by DiSa on 11/15/2012
Related ranges: Modicon Quantum





Can I create a Quantum Hot Standby configuration running one 140CPU53414A PLC with Unity firmware and one with NxT firmware?





No. When using an NxT configuration in hot standby, both PLCs must have NxT firmware. When using a Unity Quantum hot standby configuration, only specific hot standby controllers can be used. The 140CPU43412A and 140CPU53414A PLCs are not supported in Unity Hot Standby configurations.






Legacy KB System (APS) Data: RESL212766 V1.0, Originally authored by DaSo on 10/16/2013, Last Edited by DaSo on 10/16/2013
Related ranges: Modicon Quantum
