Schneider Modicon Quantum 140CPS21400C DC PS 24V 8A CC New

Quick details:

• SCHNEIDER ELECTRIC
• MODICON
• 140CPS21400C
• DC PS 24V 8A CC
• AVAILABLE
• New one with one year warranty and used one with six months warranty
• Weight: 2.00lbs

Specifications:

Technical FAQs:

• Can I create a Quantum Hot Standby configuration running one 140CPU53414A PLC with Unity firmware and one with NxT firmware?





  No. When using an NxT configuration in hot standby, both PLCs must have NxT firmware. When using a Unity Quantum hot standby configuration, only specific hot standby controllers can be used. The 140CPU43412A and 140CPU53414A PLCs are not supported in Unity Hot Standby configurations.



  ---

  Legacy KB System (APS) Data: RESL212766 V1.0, Originally authored by DaSo on 10/16/2013, Last Edited by DaSo on 10/16/2013
  Related ranges: Modicon Quantum









• Can the 140NOC77100 Quantum Ethernet IP module scan a Allen Bradley Control Logix PLC?





  The 140NOC77100 cannot scan a Allen Bradley Control Logix PLC. The reason for this is because of a proprietary way of peer to peer communication between Allen Bradley controllers. They use Produce and Consume tag in order to synchronize information between PLCs and do not have an assembly object that the 140NOC77100 can scan.




  Note: The 140NOC77100 can be an adapter to a Allen Bradley controller so the Control Logix PLC can scan the 140NOC77100.





  ---

  Legacy KB System (APS) Data: RESL196849 V1.0, Originally authored by MiMe on 01/21/2009, Last Edited by MiMe on 01/21/2009
  Related ranges: Modicon Quantum









• Do I have to power cycle the PLC in order to recognize a switch change from RTU to MEM on the 140NOM21200?





  If your using a Unity Quantum PLC you will have to cycle power. If your using a Non Unity Quantum PLC you will not have to perform a power cycle.





  ---

  Legacy KB System (APS) Data: RESL204695 V1.0, Originally authored by DaSo on 03/03/2011, Last Edited by DaSo on 03/03/2011
  Related ranges: Modicon Quantum



ConneXium™ managed switches (continued) Predefined configuration files (continued) Example topology with predefined configuration files C5, C1 and C3 (1) A common use of this preconfiguration is for interfacing a copper link with a fiber optic link on the primary ring or interfacing a fiber optic link with a copper link. This type of architecture makes it possible to have Ethernet DIO or Ethernet RIO drops some distance away from the PLC. The switch preconfiguration also enables Ethernet RIO and/or several Ethernet DIO device clouds to be connected to a secondary ring.

1  Primary ring, copper/fiber optic medium

2  Ethernet DIO secondary ring, copper medium only

3  Ethernet head adaptor 140CRP31200 installed in the Quantum™ rack.

4  ConneXium switch TCSESM083F23F1 with predefined configuration file C2 (2)

5  ConneXium switch TCSESM063F2CU1/CS1 with predefined configuration file C6 (2)

6  ConneXium switch TCSESM063F2CU1/CS1 with predefined configuration file C4 (2)

7  Modicon™ STB Ethernet DIO (3) (4)

8  Connection to Ethernet DIO device cloud, copper medium only

9  Ethernet DIO device cloud (3)

10  Ethernet communication module 140NOE771

11  Ethernet Interlink cable TCSECN3M3M1S4/1S4U (1 m)
