TCD3000 Series Control Circuit Board CC-TAIX01 51308363-175 Rev B Rosemount PLC

Contorl Circuit Board Honeywell CC-TAIX01 51308363-175 Rev B Rosemount PLC

SIMILAR PRODUCTS

51402089-100 EPDG2 EPDG2 Interface Card
51402447-100 EPDGC-1 EPDGC-1 I/O
51402447-200 EPDGC-2 EPDGC-2 I/O
51403135-100 Touch Screen Assy 21" Z
51403157-200 AUX PWR SUPPLY ASSY
51403158-100 Brightness/Contrast Buttn
51403165-400 Keyboard Tray Assembly Z
51108899-100 LCNFL LCNFL Paddle Board
51109701-100 MP-DFDTM2 MP-DFDTM2 Floppy Disk Dr
51109818-100 U.S. Media Pwr Supply
51109919-100 Clock Source Board
51195156-100 20Meg Bernoulli
51195156-200 Beta 20A Bernoulli
51195156-300 20ZA Meg Bernoulli Drive
51196483-100 150 MB Bernoulli Drive
51196929-135 Zip Drive 3.5 Internal Zip Drive
51303642-300 US Annuciator - Z Style
51304270-100 EPDG I/O EPDG I/O
51304584-100 EPDGP I/O EPDGP I/O Board
51304584-200 EPDGP EPDGP I/O Card




QUICK DETAILS

1. Brand :Honwell
2. Model : CC-TAIX01 51308363-175
3. Place of Origin : USA


DESCRIPTION

• Contorl Circuit  Board
• PC BOARD
• Rosemount PLC

This point provides built-in structures for handling interlocks. It supports operator display of interlock conditions in group, detail, and graphic displays.

Displays also contain information needed to trace interlock cause. In addition, provision is made for operation of hand/off/auto switches commonly used for local operation of motorized devices.

The major parameters associated with the Digital Composite point are represented pictorially in Figure 5. Runtime maintenance statistics for the discrete device are also supported.

Logic Point

A Logic point provides a configurable mix of logic capability. Together with a digital composite point, it provides the basis for integrated interlock logic functions. Conceptually, a Logic point can be thought of as the logic processing equivalent to one to two pages of relay ladder logic. A Logic point consists of logic blocks, flags, numerics, input connections, and output connections. Different mixes of inputs, outputs, and logic blocks can be optionally selected. Maximums for each type are shown in Table 3.

User Programs— Process Module Point

Today’s control strategies frequently need the flexibility of user programs that can be utilized for continuous, batch, or hybrid applications. A Process Module point is a resource for the execution of user-created programs written in Honeywell’s Control Language (CL/APM).

The CL language provides an outstanding sequential control and computational tool. CL programs are self-documenting— an important feature when future modification of control strategies is anticipated. The total statement capacity depends on configuration. Typically 10,000 to 20,000 CL/APM statements can be handled by a single APM. Using the Universal Station or Universal Work Station, individual programs can be easily modified and reloaded without affecting execution of regulatory control, logic blocks, and other user programs.

All process module programs can access the Advanced Process Manager database, thereby accessing analog inputs and outputs, digital inputs and outputs, array points, logic block states, alarm states, and failure states, numeric variables, and flags.
