NEW DeltaV DUAL RIGHT EXTENDER KJ4001X1-NA1 12P3373X012 Power Supply Redundant Module

Superb delivery a great product, perfect communication as well !! A++++

—— Carlos

Great deal. Fast shipping and good service.Recommended !!!!!!!!!

—— Gita

I'm Online Chat Now

NEW DeltaV DUAL RIGHT EXTENDER KJ4001X1-NA1 12P3373X012 Power Supply Redundant Module

Large Image :  NEW DeltaV DUAL RIGHT EXTENDER KJ4001X1-NA1 12P3373X012 Power Supply Redundant Module

Product Details:

Place of Origin: U.S.A / Thailand / UK
Brand Name: Emerson
Certification: CE
Model Number: KJ4001X1-NA1

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Contact us
Packaging Details: New Original Box
Delivery Time: 2-3 work days
Payment Terms: T/T / Paypal
Supply Ability: 50
Detailed Product Description
Model: KJ4001X1-NA1 TYPE: DUAL RIGHT EXTENDER
PN: 12P3373X012 Condition: NEW
System: Fisher-Rosemount System Brand: Emerson DeltaV
High Light:

plc power supply module

,

diode redundancy module

NEW DeltaV DUAL RIGHT EXTENDER KJ4001X1-NA1 12P3373X012 Power Supply Redundant Module





Description



Model Type:
KJ4001X1-NA1



Part No:

12P3373X012


Manufacturer(s)
Emerson, Fisher-Rosemount





Similiar Models



KJ4003X1-BH3
KJ4005X1-BD1
KJ4001X1-NA1
KJ4001X1-NB1
KJ4001X1-NA1
KJ4003X1-BH1
KJ4003X1-BH4





I.Single Carrier Layout combined with SIS



Suitable for 800 mm wide cabinets. This arrangement is typically limited to 5 carriers within one cabinet.



Note:



  • Controller 2-wide carriers and 1-wide extenders are not counted in the calculation.
  • The I/O LocalBus starts at the right side of the right-hand controller.
  • Adding 2-wide carriers to support additional System Power supplies or to add VIMs does not change the LocalBus calculation.
  • All SIS related single parts will count as for M-Series specified.



II.Dual Carrier Layout combined with SIS



Suitable for 1200 mm wide cabinets. This arrangement allows for 8 carriers within one cabinet.



Note:



  • Controller 2-wide carriers and 1-wide extenders are not counted in the calculation.
  • The I/O LocalBus starts at the right side of the right-hand controller.
  • Adding 2-wide carriers to support addition System Power supplies or to add VIMs does not change the LocalBus calculation.
  • All SIS related single parts will count as for M-Series specified.



III.Triple Carrier Layout combined with SIS



Suitable for 1600 mm wide cabinets. This arrangement allows 8 carriers within one cabinet.



Note:

  • Controller 2-wide carriers and 1-wide extenders are not counted in the calculation.
  • The I/O LocalBus starts at the right side of the right-hand controller.
  • Adding 2-wide carriers to support addition System Power supplies or to add VIMs does not change the LocalBus calculation.
  • All SIS related single parts will count as for M-Series specified.




System Compatibility

M-series Traditional I/O cards are not physically compatible with S-series controller carriers.
The following traditional I/O Plus cards require v13.3.1 or higher Software:
„
  • AI Plus, 4-20 mA HART, 16 Channels.
  • AO Plus, 4-20 mA HART, 16 Channels.
  • DI Plus, 32-channel, 24V DC Dry contact.
  • DO Plus, 32-channel, 24V DC High-Side.

Analog Input Cards and Termination Blocks

Description Model Number
8 Channels 4-20 mA, HART Standard I/O Termination Block VE4003S2B1
Redundant Standard I/O Termination Block
VE4033S2B1
Fused I/O Termination Block VE4003S2B2
4-wire I/O Termination Block VE4003S2B3
16-Pin Mass Termination Block VE4003S2B4
24-Pin Mass Termination Block VE4003S2B5
16 Channels 4-20 mA, HART Standard I/O Termination Block VE4003S2B6
4-wire I/O Termination Block 16 Channels 4-20 ma, HART, Plus Card VE4003S2B7
16-Channel 2-Wire AI Terminal Block for Series 2 Plus VE4003S2B9
16-Channel 4-Wire AI Terminal Block for Series 2 Plus VE4003S2B10
Redundant 16-Channel 2- & 4-Wire AI Terminal Block for Series 2 Plus VE4033S2B10
8 Channels Thermocouple,mV Standard I/O Termination Block VE4003S4B1
Cold Junction Compensated (CJC) Termination Block VE4003S5B1

Analog Input Card: 8 Channels RTD

Resistant Temperature Device (RTD) Termination Block

VE4003S6B1
Isolated Input Card
Isolated Input Terminal Block
VE4003S7B1
Standard I/O Termination Block VE4005S2B1
Redundant Standard I/O Termination Block VE4035S2B1
Fused I/O Termination Block VE4005S2B2
16-Pin Mass Termination Block VE4005S2B3
16-Channel AO Terminal Block for Series 2 Plus VE4005S2B4
Redundant 16-Channel AO Terminal Block for Series 2 Plus VE4035S2B4

Standard I/O Termination Block

VE4001S2T1B1
Fused I/O Termination Block VE4001S2T1B2
Standard I/O Termination Block VE4001S2T2B1
Redundant Standard I/O Termination Block VE4031S2T2B1
Fused I/O Termination Block
VE4001S2T2B2
16-Pin Mass Termination Block VE4001S2T1B3
16-Pin Mass Termination Block VE4001S2T2B3
Standard Termination Block VE4001S2T2B4
40-pin Mass Termination Block
VE4001S2T2B5
Redundant32-Channel DI Terminal Block for Series 2 Plus VE4031S2T2B6
40-pin DI Mass Termination Block for Series 2 Plus  (to be used with P+F HiD or HiC IS barriers and termination boards for DeltaV DCS)
VE4001S2T2B7
40-pin DI Mass Termination Block for Series 2 Plus including 2 x 16-channel DI Plus Mass Connection Boards*
VE4051S2T2B7
Redundant 40-pin DI Mass Termination Block for Series 2 Plus (to be used with P+F HiD or HiC IS barriers and termination boards for DeltaV DCS)
VE4031S2T2B7
Redundant 40-pin DI Mass Termination Block for Series 2 Plus including 2 x 16-channel DI Plus Mass Connection Boards *
VE4081S2T2B7
Standard I/O Termination Block VE4001S3T1B1
Fused I/O Termination Block VE4001S3T1B2
Standard I/O Termination Block VE4001S3T2B1
Fused I/O Termination Block VE4001S3T2B2
Discrete 32 Channel Terminal Block VE4015
Discrete 32-Channel Terminal Block
VE4001S5T2B4
40-pin Mass Terminal Block VE4001S5T2B5
Standard I/O Termination Block VE4002S1T1B1
Fused I/O Termination Block VE4002S1T1B2
16-Pin Mass Termination Block VE4002S1T1B3
Standard I/O Termination Block
VE4002S1T2B1
Redundant Standard I/O Termination Block VE4032S1T2B1
Fused I/O Termination Block VE4002S1T2B2
16-Pin Mass Termination Block VE4002S1T2B3
10-Pin Mass Termination Block VE4002S1T2B4
Standard I/O Termination Block VE4002S1T2B5
40-Pin Mass Termination Block VE4002S1T2B6
40-pin DO Mass Termination Block for Series 2 Plus (to be used with P+F HiD or HiC IS barriers and termination boards for DeltaV DCS)
VE4002S1T2B8
40-pin DO Mass Termination Block for Series 2 Plus including 4 x 8-channel DO Mass Connection Boards *
VE4052S1T2B8
Redundant 40-pin DO Mass Termination Block for Series 2 Plus (to be used with P+F HiD or HiC IS barriers and termination boards for DeltaV DCS)
VE4032S1T2B8
Redundant 40-pin DO Mass Termination Block for Series 2 Plus including 4 x 8-channel DO Mass Connection Boards *
VE4082S1T2B8
Standard I/O Termination Block VE4002S2T1B1
Fused I/O Termination Block VE4002S2T1B2
Standard I/O Termination Block
VE4002S2T2B1
Fused I/O Termination Block VE4002S2T2B2
250V 2A Fuse for Fused Terminal Block; Box of 20
KJ4010X1-BC1
