IC693CPU364 Ethernet Interface Module / Delta Analog Input Module With Ethernet Comms

Large Image :  IC693CPU364 Ethernet Interface Module / Delta Analog Input Module With Ethernet Comms

Product Details:

Place of Origin: USA
Brand Name: GE Fanuc
Model Number: IC693CPU364

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: negotiable
Packaging Details: New in original box
Delivery Time: 2-3 work days
Payment Terms: T/T, Western Union
Detailed Product Description
Brand: GE Fanuc Model 1: IC693CPU364
Model 2: IC693CPU364-FK Model 3: IC693CPU364-CJ
Model 4: IC693CPU364-AC Place Of Origin: USA
Model 5: IC693CPU364-AB Model 6: IC693CPU364-CGI

Redundant Power Supply Module GE Fanuc IC693CPU364 CPU Module with Ethernet Comms











CPU Type  Single slot CPU module with embedded Ethernet Interface
Total Baseplates per System 8 (CPU baseplate + 7 expansion and/or remote)
Load Required from Power Supply 1.51 Amps from +5 VDC supply
Processor Speed 25 MegaHertz
Processor Type 80386EX
Ethernet fuse, replaceable 2.69x2.69x6.1 mm, 125V, 1A, slow acting
Operating temperature 0 to 60 degrees C (32 to 140 degrees F) ambient
Typical Scan Rate 0.22 milliseconds per 1K of logic (boolean contacts)
User Memory (total) 240K Bytes. Note: Actual size of available user program memory
depends on the amounts configured for %R, %AI, and %AQ
configurable word memory types (see below).
Discrete Input Points - %I 2,048
Discrete Output Points - %Q 2,048
Discrete Global Memory - %G 1,280 bits
Internal Coils - %M 4,096 bits
Output (Temporary) Coils - %T 256 bits
System Status References - %S 128 bits (%S, %SA, %SB, %SC - 32 bits each)
Register Memory - %R Configurable in 128 word increments from 128 to 16,384 words
with Logicmaster and from 128 to 32,640 words with Control
version 2.2.
Analog Inputs - %AI Configurable in 128 word increments from 128 to 16,384 words
with Logicmaster and from 128 to 32,640 words with Control
version 2.2.
Analog Outputs - %AQ Configurable in 128 word increments from 128 to 16,384 words
with Logicmaster and from 128 to 32,640 words with Control
version 2.2.
System Registers (for reference tableviewing only; cannot be referenced in logic program)
28 words (%SR)
Timers/Counters >2,000
Shift Registers Yes
Built-in Serial Ports 1 (uses connector on PLC Power Supply). Supports SNP/SNPX
slave. Requires CMM module for SNP/SNP-X master, RTU slave,or CCM; PCM module for RTU master support.
Communications Ethernet (internal) - AAUI or 10BASE-T. AAUI requires
external transceiver. 10BASE-T is direct.
Ethernet (additional) - Supports Ethernet option modules.LAN-Requires option modules for Genius, Profibus, FIP.
Override Yes
Battery Backed Clock Yes
Interrupt Support Supports the periodic subroutine feature.
Type of Memory Storage RAM and Flash
PCM/CCM Compatibility Yes
Floating Point Math Support Yes, firmware-based





Note: On some early modules, the LED labeled “PS PORT” may say “SNP” instead; otherwise, the modules are identical.










OTHER SUPERIOR PRODUCTS

Yasakawa Motor, Driver SG- Mitsubishi Motor HC-,HA-
Westinghouse Modules 1C-,5X- Emerson VE-,KJ-
Honeywell TC-,TK- GE Modules IC -
Fanuc motor A0- Yokogawa transmitter EJA-



Contact person: Anna
E-mail: wisdomlongkeji@163.com
Cellphone: +0086-13534205279






Similar Products

GE FANUC IC610MDL175B Output Module
GE FANUC IC693MDL940F Output Module
GE FANUC IC693MDL240E Input Module
GE FANUC CR545PAA12P LOGITROL BD
GE FANUC A16B2203037007C Power Supply
GE FANUC IC697CMM711P COPROCESSOR
GE FANUC IC697CPX935CD CENTRAL PROCESSING UNIT
GE FANUC IC693CHS399 BASE REMOTE EXPANSION 5 SLOTS
GE FANUC IC610MDL112A PLC
GE FANUC IC610CBL101A Programmable Controller I/O Expander Cable
GE FANUC IC600BF841L INPUT MODULE ANALOG 0-10VDC SERIES SIX
GE FANUC IC600CB503A GE Programmable Controller Card
GE FANUC IC600CB503L GE Prgrammable Controller Card
GE FANUC IC600CB525K GE Programmable Controller Card
GE FANUC IC600LX616K Series 6 Memory Card
GE FANUC IC600CB500A GE Programmable Controller Card
GE FANUC IC600PM542A GE Programmable Controller Card
GE FANUC IC693MDL645D 24V POS/NEG INPUT
GE FANUC IC600BF923K GE Programmable Controller Card
GE FANUC IC600BF921K GE Programmable Controller Card
GE FANUC IC600PM503KE Series 6 Power Supply
GE FANUC IB600BF902K GE Programmable Controller Card
GE FANUC IC600BF914K GE Programable Controller Card
GE FANUC IC600YB800B GE Programmable Controller Card
GE FANUC IC600PM503K GE Programmable Controller Card
GE FANUC IC600YB831C GE Programmable Controller Card
GE FANUC IC600BF800K GE Programmable Controller Card
GE FANUC IC660ELD021B 16 Channel 24-48 V Sink In/Out
GE FANUC IC600BF831K GE Programmable Controller Card
GE FANUC IC600BF902K GE Programmable Controller Card
GE FANUC IC693CPU364 CPU MODULE 240K BYTES CONFIGURABLE USER MEMORY









The GE Fanuc 90-30 IC693CPU364 is a single slot CPU that has user programabale memory Depends on assigned values for configurable word memory (%R, %AQ, %AI) at a maximum of 240K Bytes and register memory configurable from 128 to 32,640 words, in 128 word increments. With 1 built in port the GE Fanuc 90-30 IC693CPU364 supports SNP/SNP-X master CCM, or RTU slave support; PCM module for RTU master support. GE Fanuc 90-30 IC693CPU364 has a processor speed of 25 megahertz.





The IC693CPU364 is a single-slot Central Processing Unit (from the GE Fanuc Series 90-30) with an embedded Ethernet cord and 1 built-in serial port. This unit is the "brains" of the PLC and is where most of the calculations take place. See specifications for this unit on IC693CPU364's website page. A standard application for IC693CPU364 would be connecting a computer's 9-pin serial port via IC693CBL316 to IC693CPU364's standard Ethernet interface. It should be noted that IC693CPU364's Ethernet interface is Ethernet Global Data (EGD). The benefit of this built in Ethernet interface is that you do not need to use a separate Ethernet module such as CMM321 with the unit. You can, in fact, save a PLC slot based on the built in nature of an Ethernet port on IC693CPU364.





The EGD also allows CPU364 to handle specialized parameters which HHP's configuration mode is not able to do. Unlike CMM321, CPU364 does not require an external transceiver. CPU364 has a built in transceiver that can be connected to via the 10BASE-T port. CPU364 does offer some added functionality in the ability to add an external transceiver as well though. This can be done via the AAUI port which bypasses the internal transceiver. Another benefit of the built in Ethernet interface is that it can communicate without using the PLC backplane, creating faster communications speed than could be achieved with separate CPU and Ethernet modules. Some basic things to note regarding IC693CPU364 are that when using CPU364 you must connect to frame ground at the slot where it is installed. You can find a grounding wire on the unit for this very use.





CPU364 uses flash firmware standard with no EPROM, and no EEPROM. The current rating on IC693CPU364 is 1A and it uses GE Fanuc Fuse 44A725214–001. The maximum CPU capacity for CPU364 is 25 MHz utilizing the 80386EX processor. There are 2048 input points, 2048 output points. Register memory is configurable from 128 to 32640 words. CPU364 has firmware-based floating point math.







With Firmware Release 9.1 the EGD and configurable Name Resolution features were added to the CPU364.CPU364 has four LED lights, an Ethernet Restart button, a standard CPU keyswitch, three port connectors, and a shield ground connection tab. The four LED indicator lights pertain to the Ethernet interface and the PS port. Three of the lights are for Ethernet: EOK, LAN, and STAT, and 1 is for the PS port. The Ethernet Restart button has four uses:

  • LED test
  • Restart
  • Restart and enter Software Load state
  • Restart and enter Maintenance state



CPU364 has a Port 1, RS-232, AAUI port, and 10Base T port. These ports allow CPU364 to be connected to a terminal or terminal emulator (PORT 1), connect via IEEE 802.3 to an external Ethernet transceiver (AAUI), and to connect wo a 10Base T Ethernet network.The firmware on CPU364 is, as stated above, stored in Flash memory and loaded via the serial port connector. This is done using a personal computer with loader and software. Similarly, the Ethernet Interface firmware is stored in Flash memory and loaded through the Port 1 connector in the same manner.





The IC693CPU364 is equipped with 8 baseplates, which consist of a single CPU baseplate and 7 baseplates that can either serve as expansion or remote baseplates. It uses an 80386EX processor running at 25 MHz and requires a load of 1.51 amps from +5 VDC power supply. It also has a slow acting, replaceable Ethernet fuse of size 2.69 x 2.69 x 6.1 mm, with a voltage of 125V and a current of 1 A. The module operates with an ambient temperature ranging from 0 to 60 degrees Celsius (or 32 to 140 degrees Fahrenheit). It has a typical scan rate of 0.22 milliseconds per 1K of logic or Boolean contacts.







The IC693CPU364 has up to 240K bytes of program memory available for the user. Please note: the actual size of available user program memory depends on the amounts configured for %R, %AI, and %AQ configurable word memory types as outlined below. Its register memory (%R) is configurable in increments of 128 words, from 128 to 16,384 words with Logicmaster and from 128 to 32,640 words with Control version 2.2. It comes installed with a discrete global memory (%G) of 1280 bits, internal coils (%M) of 4096 bits, output (temporary) coils (%T) of 256 bits, and system status references (%S) of 128 bits (with %S, %SA, %SB, %SC having 32 bits each).







Analog inputs (%AI) and outputs (%AQ) are both configurable in increments of 128 words, from 128 to 16,384 words with Logicmaster and from 128 to 32,640 words with Control version 2.2. Discrete input (%I) and output (%Q) outputs are 2,048 each. It has 28 words (%SR) system registers which are used for reference table viewing only and cannot be referenced in user logic program. It supports RAM and flash memory types and has a firmware based floating point math support.







It has shift registers, override, battery-backed clock, with interrupts that support the periodic subroutine feature, and over 2000 timers/counters. It only has one built-in serial port which uses a connector on the PLC power supply. The port supports SNP/SNP-X slave protocols.





The module has PCM/CCM compatibility; however, in order to support SNP/SNP-x master, CCM, or RTU slave support, it requires a CMM module. It also requires a PCM module to support RTU master. It has an internal AAUI or 10BASE-T Ethernet (the AAUI requires external transceiver while the 10BASE-T is direct). It also has an additional external Ethernet that supports Ethernet option modules.





The installed Local Area Network (LAN) requires option modules for Genius, Profibus, and FIP. Earlier modules may have the LED labeled “SNP” instead of “PS PORT.” Otherwise, these modules are identical.
