Product Details:
Payment & Shipping Terms:
|
| Brand: | Schneider | Model: | 140 CRP 932 00 |
|---|---|---|---|
| Palce Of Origin: | FR | Type: | Processor/Controller |
| Bus Current: | 750 MA | Module Format: | Standard |
| Channels: | 2 | Weight: | 0.37 Kg |
| High Light: | analog interface module,diode redundancy module |
||
Redundant Power Supply Module SCHNEIDER TSX QUANTUM 140 CRP 932 00
General Specifications
Module Type 8 Channel IN Differential
External Power Not required
Bus Current required (Module) 240 mA
Power Dissipation 2 W
I/O map 9 input words
Fault Detection Broken wire (4 ... 20 mA mode) or under voltage
range (1 ... 5 V)
Voltage / Input
Operating Voltage (Channel toChannel) 30 VDC (max.)
Absolute Voltage (max.) 50 VDC
Linear Mesuring Range 1 ... 5 VDC
Input Impedance > 20 Mohms
Current / Input
Absolute Current (max.) 25 mA
Linear Measuring Range 4 ... 20 mA
Input Impedance 250 ohms + 0.003%
Resolution / Conversion
Resolution 12 bit
Absolute Accuracy Error @ 25 degrees C (voltage mode)
Typical: +/- 0.05% of full scale
Maximum: +/- 0.1% of full scale
Linearity +/- 0.04%
Accuracy drift with temperature Typical: +/- 0.0025% of full scale / degrees C
Maximum: +/- 0.005% of full scale / degrees C
Common Mode Rejection -72 dB @ 60 Hz
Input Filter Single pole low pass, -3 dB cutoff @ 15 Hz, +/-20%
Update Time 5 ms for all channels
Isolation
Channel to Bus 1000 VDC 3000 Vpp for 1 minute
OTHER SUPERIOR PRODUCTS
| Yasakawa Motor, Driver SG- | Mitsubishi Motor HC-,HA- |
| Westinghouse Modules 1C-,5X- | Emerson VE-,KJ- |
| Honeywell TC-,TK- | GE Modules IC - |
| Fanuc motor A0- | Yokogawa transmitter EJA- |
Function
The 140 ACI 040 00 is a 16 channel analog input module which accepts mixed current inputs.
Illustration
The following figure shows the140 ACI 040 00 module and its components.
1 Model Number, Module Description, Color Code
2 LED Display
3 Fuse Cutouts
4 Field Wiring Terminal Strip
5 Removable Door
6 Customer Identification Label (Fold label and place it inside door)
Note: The field wiring terminal strip (Modicon #140 XTS 002 00) must be ordered separately. (The terminal strip includes the removable door and label.)
Wiring diagram for the 140 ACI 040 00 Module.
Notes on Wiring Diagram
The current sources are supplied by the user ( fusing is at the discretion of the user.)
A shielded cables must be used. In noisy environments twisted shielded cable is recommended. Shielded cable should have a shield tied to earth ground near the
signal source end.
Unused inputs may cause the activation of the F LED. To avoid this occurrence the unused channels should be configured in the 0 ... 25 mA range.
The maximum channel to channel working voltage cannot exceed 30 VDC.
N/C = Not connected
When field wiring the I/O module, the maximum wire size that should be used is1-14 AWG or 2-16 AWG; the minimum size is 20 AWG.
Resolution / Conversion
Resolution 0 ... 25,000 counts
0 ... 20,000 counts
0 ...16,000 counts
0 ... 4,095 counts
Absolute Accuracy Error @ 25 degreesC
+/- 0.125% of full scale
Linearity (0 to 60 degrees C) +/- 12 microA max., 4 ... 20 mA
+/- 6 microA max., 0 ... 25 mA
+/- 6 microA max., 0 ... 20 mA
+/- 6 microA max., 4 ... 20 mA
Accuracy drift with temperature Typical: +/- 0.0025% of full scale / degrees C
Maximum: +/- 0.005% of full scale / degrees C
Common Mode Rejection -90 dB @ 60 Hz
Input Filter Single pole low pass, -3 dB cutoff @ 34 Hz, +/-25%
Update Time 15 ms for all channels
Parameter and Default values
Name Default Value Options Description
Mapping WORD (%IW-3X) -
Inputs Starting Address 1 -
Inputs Ending Address 9 -Task
(Grayed if module in
other than local)
MAST FAST
AUX0
AUX1
AUX2
AUX3
fixed toMAST if
module in other thanlocal
Module_Configuration
Resolution 1.0 Deg 0.1 Deg
Output Unit Centigrade Fahrenheit
Value Type Temp Raw Value
