PLC Programmable Logic Controller Emerson TOPWORX DXP-L214NEB

FOUNDATION Fieldbus digital communication:

• Link active scheduler capability/Link Master (LAS)

• Pre-instantiated** blocks include Resource Block (RB), Transducer Block (TB), Analog Input (AI) Function Block, Discrete Output (DO) Function Block, 2 Discrete Input (DI) Function Block, Proportional, Integral, and Derivative (PID) Function Block

• Function block instantiation, live download, auto commission/replacement

• Fast function block execution time: DI: 15ms, AI: 15ms, DO: 20ms, PID: 20ms

• Easy integration into AMS and DeltaV systems

• Device Dashboards powered by enhanced Electronic Device Description Language (EDDL)

Position sensing/monitoring

• Optional GO switches for open/close status

• Optional potentiometer for position percentage indication, can be used for any rotation range between 20 and 320 degrees. End position offsets are adjustable.

Control and monitor inputs and outputs

• Supports single/double and normal/reverse acting actuators

• Local LEDs for visual indication

• Local push buttons for calibration

• Remote configuration from control system or field communicator

• Stroke valve method

• Cycle count monitoring

• Open/close time monitoring

• Temperature monitoring

• Open/short circuit protection

• Integrated field diagnostics

• Embedded NAMUR NE 107 diagnostics
