| Product Name: | Input Module | Model No.: | DI802 |
|---|---|---|---|
| Article Number: | 3BSE022360R1 | Signal Specification: | 120 V A.c., 110 V D.c. |
| Number Of Channels: | 8 Channels | Signal Type: | Current Sinking |
| Type: | Analog Input | Mechanics: | S800L |
| High Light: | ethernet i o module,digital input output module |
||
ABB DI802 3BSE022360R1 S800L I/O Module DI802-eA 3BSE022364R2 Digital Input Module
Description of DI802:
The DI802 is an 8 channel 120 V a.c./d.c.digital input module for the S800 I/O. This module has 8 digital inputs. The a.c. input voltage range is 77 - 130 volt and the input current is 10 mA at 120 V a.c. The d.c. input range is 75 - 145 V and the input current is 2.8 mA at 110 V. The inputs are individually isolated. Every input channel consists of current limiting components, EMC protection components, input state indication LED and optical isolation barrier.
General Information
| Type | Digital Input |
| Signal specification | 120 V a.c., 110 V d.c. |
| Article number | 3BSE022360R1 |
| Number of channels | 8 |
| Signal type | Current sinking |
| HART | No |
| SOE | No |
| Redundancy | No |
| High integrity | No |
| Intrinsic safety | No |
| Mechanics | S800L |
I/O Modules
| AI801 | AI810 | AI815 | AI820 | AI825 |
| AI830A | AI835A | AI843 | AI845 | AI880A |
| AI890 | AI893 | AI895 | AO801 | AO810V2 |
| AO815 | AO820 | AO845A | AO890 | AO895 |
| DI801 | DI802 | DI803 | DI810 | DI811 |
| DI814 | DI818 | DI820 | DI821 | DI825 |
| DI828 | DI830 | DI831 | DI840 | DI880 |
| DI890 | DO801 | DO802 | DO810 | DO814 |
| DO815 | DO818 | DO820 | DO821 | DO828 |
| DO840 | DO880 | DO890 | DP820 | DP840 |
Detailed data
| Input voltage range, "0" | 0..30 V a.c., 0..20 V d.c. |
| Input voltage range, "1" | 77..130 V a.c., 75..145 V d.c. |
| Input impedance | 12 kΩ (a.c.) 39 kΩ (d.c.) |
| Isolation | Individually isolated channels |
| Filter times (digital, selectable) | 2, 4, 8, 16 ms |
| Input frequencey range | 47..63 Hz |
| Analog filter On/Off delay | 5 / 18 ms |
| Maximum field cable length | 200 meters (219 yards) 100 pF/m for a.c., 600 meters (656 yards) for d.c. |
| Rated insulation voltage | 250 V |
| Dielectric test voltage | 2000 V a.c. |
| Power dissipation | Typ. 2.8 W |
| Current consumption +5 V Modulebus | 50 mA |
| Current consumption +24 V Modulebus | 0 |
| Current consumption +24 V external | 0 |
Diagnostics
| Front LED’s | S(tatus) (run or fault), Channel 1-16 ("0" or "1") |
| Supervision | Process voltage supervision on channel 8 |
| Status indication of supervision | Module Error, Module Warning, Channel Error |
Features and benefits
Environment and certification
| CE mark | Yes |
| Electrical safety | IEC 61131-2, UL 508 |
| Hazardous Location | - |
| Marine certification | ABS, BV, DNV-GL, LR, RS, CCS |
| Protection rating | IP20 according to IEC60529 |
| Corrosive atmosphere ISA-S71.04 | G3 |
| Climatic operating conditions | 0 to +55 °C (Storage -40 to +70 °C), RH=5 to 95 % no condensation, IEC/EN 61131-2 |
| Pollution degree | Degree 2, IEC 60664-1 |
| Mechanical operating conditions | IEC/EN 61131-2 |
| EMC | EN 61000-6-4 and EN 61000-6-2 |
| Overvoltage categories | IEC/EN 60664-1, EN 50178 |
| Equipment class | Class I according to IEC 61140; (earth protected) |
| Max ambient temperature | 55 °C (131 °F), for vertical mounting 40 °C (104 °F) |
| RoHS compliance | EN 50581:2012 |
| WEEE compliance | DIRECTIVE/2012/19/EU |
Dimensions
| Height | 110 mm (4.33”) |
| Width | 86.1 mm (3.4”) |
| Depth | 58.5 mm (2.3”) |
| Weight | 0.24 kg (0.53 lbs.) |
