Product Details:
Payment & Shipping Terms:
|
| Brand: | Schneider | Model: | 140CPU65150C |
|---|---|---|---|
| Country Of Origin: | France | Type: | Modicon Quantum Automation Platform |
| Product Or Component Type: | Unity Processor | Clock Frequency: | 266 MHz |
| MOQ: | 1 PIECE | Deliver: | 1 Weeks |
| High Light: | modicon quantum processor,modicon quantum cpu |
||
140CPU65160C Modicon Quantum PLC CPU Single Slot 80486 Processor With Mathematical
Quick details:
More Info on the 140CPU65160C
Unity Processor Modicon Quantum - 1024 Kb - 266Mhz
Quantum | 140CPU65160C | Modicon | 140 CPU 651 60C | Processor UNITY W/ 2048/7168K Ethernet
The 140 CPU 651 50 , 140 CPU 651 60 and 140 CPU 652 60 processors have the following on the front panel: 4 An RJ45 connector for the connection to the Modbus bus. 5 A type B female USB connector for connecting the programming PC 6 A 9-way female SUB-D connector for the connection to the Modbus Plus network 7 Two slots for PCMCIA memory extension cards 8 Two LEDs marked COM and ERR 9 An RJ45 connector for the connection to the Ethernet network.
Specifications:
|
Manufacturer: |
Modicon Quantum |
|
Series: |
Quantum CPUs |
|
Weight: |
2 lb |
|
Product or component: |
Unity processor |
|
Clock frequency: |
266 MHz |
|
Number of slots: |
10 |
|
|
16 |
|
|
2 |
|
|
4 |
|
|
6 |
|
Number of racks: |
2 - local rack(s) |
|
Number of distributed I/O station: |
63 station(s) - 1 rack(s) - 3 distributed network(s) |
|
Number of remote I/O station: |
31 - 2 remote rack(s) |
|
Discrete I/O number: |
8000 inputs, 8000 outputs - distributed - per network |
|
|
31744 inputs, 31744 outputs - remote |
|
|
Unlimited (26 slots max) - local |
|
Analogue I/O number: |
Unlimited (26 slots max) - local |
|
|
500 inputs, 500 outputs - distributed - per network |
|
|
1984 inputs,1984 outputs - remote |
|
Application specific I/O: |
Accurate time stamping |
|
|
Counter |
|
|
High-speed interrupt inputs |
|
|
Serial link |
|
Number of optional modules: |
6 (Ethernet, Modbus, Modbus Plus, Profibus DP, Sy/Max) |
|
Maximum number of connections: |
Unlimited (AS-Interface) - local |
|
|
6 (Profibus DP) - local |
|
|
6 (Modbus Plus) - local |
|
|
6 (Ethernet TCP/IP) - local |
|
|
4 (AS-Interface) - remote |
|
|
2 (AS-Interface) - distributed |
|
|
1 (USB) |
|
|
1 (Modbus) - RS232/485 Modbus/ASCII |
|
Integrated connection type: |
1 Ethernet TCP/IP |
|
|
1 Modbus |
|
|
1 Modbus Plus |
|
|
1 USB |
|
Checks: |
Process control |
|
Memory description: |
Expandable 8 MB - file storage with PCMCIA card |
|
|
Expandable 7168 kB - program with PCMCIA card |
|
|
Internal RAM 768 kB |
|
Switch function: |
Key switch memory port on/off |
|
Application structure: |
4 auxiliary tasks |
|
|
32 timer interrupt tasks |
|
|
128 interrupt tasks |
|
|
128 I/O interrupt tasks |
|
|
1 periodic fast task |
|
|
1 cyclic/periodic master task |
|
Execution time per instruction: |
0.48...0.56 µs floating points |
|
|
0.0525...0.075 µs Boolean |
|
|
0.045...0.06 µs on word |
|
|
0.045...0.06 µs on fixed-point arithmetic |
|
Execution time for 1 K instruction: |
9.91 65 % Boolean and 35 % numerical |
|
|
10.28 100 % Boolean |
|
System overhead: |
1 ms - master task |
|
|
0.2 ms - fast task |
|
Bus current requirement: |
2160 mA |
|
Local signalling: |
1 LED red for Ethernet collision |
|
|
1 LED green for Ethernet activity (COM) |
|
Electrical connection: |
1 female connector, connector type: SUB-D 9 for connecting to the Modbus Plus |
|
|
network |
|
|
1 connector, connector type: RJ45 for connecting Modbus bus |
|
|
1 connector, connector type: RJ45 for connecting Ethernet network |
|
|
1 connector, connector type: MT-RJ (fiber optic) for interconnecting primary and |
|
|
secondary PLCs (hot standby architecture |
Dimensions of Modules and Racks:
(1) 2 slots
(2) 3 slots
(3) 4 slots
(4) 6 slots
(5) 10 slots
(6) 16 slots
