Product Details:
Payment & Shipping Terms:
|
| Model: | KJ3242X1-BA1 | MODEL: | VE4017PO |
|---|---|---|---|
| PN: | 12P2471X022 | Series: | S2 |
| System: | Fisher-Rosemount System | Brand: | Emerson DeltaV |
| High Light: | plc power supply module,diode redundancy module |
||
Emerson DeltaV Power Supply Redundant Module KJ3242X1-BA1 12P2471X022 VE4017PO
Description
Part Number:
12P2506X042
Model Type:
KJ3242X1-BA1
Manufacturer(s)
Emerson, Fisher-Rosemount
Model(s)
Emerson Delta V KJ3242X1-BA1 12P2471X022 VE4017PO Fieldbus H1 Series 2
Estimated Shipping Size
Dimensions: 2" x 5" x 5" (5 cm x 13 cm x 13 cm)
Weight: 0 lbs 4 oz (0.11 kg)
| LocalBus power rating | 12 VDC at 300 mA |
| Fieldbus Power | 9 to 32 VDC, 12 mA per port |
Environmental Specifications
| Ambient Temperature | -40 to 70℃ |
| Shock | 10g ½ Sinewave for 11 msec |
| Vibration |
1mm Peak to Peak from 5 to 16Hz;
0.5g from 16 to 150Hz
|
| Airborne Contaminants |
ISA-S71.04–1985 Airborne
Contaminants Class G3
|
| Relative Humidity | 5 to 95% Non-Condensing IP 20 Rating |
| Terminal block key position | D6 |
| Description | Model Number |
| 8 Channels 4-20 mA, HART Standard I/O Termination Block | VE4003S2B1 |
|
Redundant Standard I/O Termination Block
|
VE4033S2B1 |
| Fused I/O Termination Block | VE4003S2B2 |
| 4-wire I/O Termination Block | VE4003S2B3 |
| 16-Pin Mass Termination Block | VE4003S2B4 |
| 24-Pin Mass Termination Block | VE4003S2B5 |
| 16 Channels 4-20 mA, HART Standard I/O Termination Block | VE4003S2B6 |
| 4-wire I/O Termination Block 16 Channels 4-20 ma, HART, Plus Card | VE4003S2B7 |
| 16-Channel 2-Wire AI Terminal Block for Series 2 Plus | VE4003S2B9 |
| 16-Channel 4-Wire AI Terminal Block for Series 2 Plus | VE4003S2B10 |
| Redundant 16-Channel 2- & 4-Wire AI Terminal Block for Series 2 Plus | VE4033S2B10 |
| 8 Channels Thermocouple,mV Standard I/O Termination Block | VE4003S4B1 |
| Cold Junction Compensated (CJC) Termination Block | VE4003S5B1 |
|
Analog Input Card: 8 Channels RTD Resistant Temperature Device (RTD) Termination Block |
VE4003S6B1 |
|
Isolated Input Card
Isolated Input Terminal Block
|
VE4003S7B1 |
| Standard I/O Termination Block | VE4005S2B1 |
| Redundant Standard I/O Termination Block | VE4035S2B1 |
| Fused I/O Termination Block | VE4005S2B2 |
| 16-Pin Mass Termination Block | VE4005S2B3 |
| 16-Channel AO Terminal Block for Series 2 Plus | VE4005S2B4 |
| Redundant 16-Channel AO Terminal Block for Series 2 Plus | VE4035S2B4 |
|
Standard I/O Termination Block |
VE4001S2T1B1 |
| Fused I/O Termination Block | VE4001S2T1B2 |
| Standard I/O Termination Block | VE4001S2T2B1 |
| Redundant Standard I/O Termination Block | VE4031S2T2B1 |
| Fused I/O Termination Block |
VE4001S2T2B2
|
| 16-Pin Mass Termination Block | VE4001S2T1B3 |
| 16-Pin Mass Termination Block | VE4001S2T2B3 |
| Standard Termination Block | VE4001S2T2B4 |
|
40-pin Mass Termination Block
|
VE4001S2T2B5 |
| Redundant32-Channel DI Terminal Block for Series 2 Plus | VE4031S2T2B6 |
|
40-pin DI Mass Termination Block for Series 2 Plus (to be used with P+F HiD or HiC IS barriers and termination boards for DeltaV DCS)
|
VE4001S2T2B7 |
|
40-pin DI Mass Termination Block for Series 2 Plus including 2 x 16-channel DI Plus Mass Connection Boards*
|
VE4051S2T2B7 |
|
Redundant 40-pin DI Mass Termination Block for Series 2 Plus (to be used with P+F HiD or HiC IS barriers and termination boards for DeltaV DCS)
|
VE4031S2T2B7 |
|
Redundant 40-pin DI Mass Termination Block for Series 2 Plus including 2 x 16-channel DI Plus Mass Connection Boards *
|
VE4081S2T2B7 |
| Standard I/O Termination Block | VE4001S3T1B1 |
| Fused I/O Termination Block | VE4001S3T1B2 |
| Standard I/O Termination Block | VE4001S3T2B1 |
| Fused I/O Termination Block | VE4001S3T2B2 |
| Discrete 32 Channel Terminal Block | VE4015 |
|
Discrete 32-Channel Terminal Block
|
VE4001S5T2B4 |
| 40-pin Mass Terminal Block | VE4001S5T2B5 |
| Standard I/O Termination Block | VE4002S1T1B1 |
| Fused I/O Termination Block | VE4002S1T1B2 |
| 16-Pin Mass Termination Block | VE4002S1T1B3 |
| Standard I/O Termination Block |
VE4002S1T2B1
|
| Redundant Standard I/O Termination Block | VE4032S1T2B1 |
| Fused I/O Termination Block | VE4002S1T2B2 |
| 16-Pin Mass Termination Block | VE4002S1T2B3 |
| 10-Pin Mass Termination Block | VE4002S1T2B4 |
| Standard I/O Termination Block | VE4002S1T2B5 |
| 40-Pin Mass Termination Block | VE4002S1T2B6 |
|
40-pin DO Mass Termination Block for Series 2 Plus (to be used with P+F HiD or HiC IS barriers and termination boards for DeltaV DCS)
|
VE4002S1T2B8 |
|
40-pin DO Mass Termination Block for Series 2 Plus including 4 x 8-channel DO Mass Connection Boards *
|
VE4052S1T2B8 |
|
Redundant 40-pin DO Mass Termination Block for Series 2 Plus (to be used with P+F HiD or HiC IS barriers and termination boards for DeltaV DCS)
|
VE4032S1T2B8 |
|
Redundant 40-pin DO Mass Termination Block for Series 2 Plus including 4 x 8-channel DO Mass Connection Boards *
|
VE4082S1T2B8 |
| Standard I/O Termination Block | VE4002S2T1B1 |
| Fused I/O Termination Block | VE4002S2T1B2 |
|
Standard I/O Termination Block
|
VE4002S2T2B1
|
| Fused I/O Termination Block | VE4002S2T2B2 |
| 250V 2A Fuse for Fused Terminal Block; Box of 20 |
KJ4010X1-BC1
|
