Yaskawa 2.0KW Servopack 200-230V Input 18.5AMPS SGDB Series SGDB-20AN

Yaskawa 2.0KW Servopack 200-230V Input 18.5AMPS SGDB Series SGDB-20AN

Quick Details

Product number: SGDB-20AN
Description: SGDB-20ANG is an Drives-AC Servo
Drive Type: SGDB AC Servo Drive
Rated Output: 2.0kW
Supply Voltage: 200V
Frequency:50/60HZ
Model: Torque, Speed, Position Control
Applicable motor series: SGMG
Option Specifications: None
Modification: None

The SGDB Sigma Series Servopacks are Amplifiers for the Sigma Series of AC Servos. Designed for applications requiring multi-drives, the SGDB can be used for speed control, torque control, and position control. A digital operator can be used to set parameters for a Servopack.

Features
230VAC Three-Phase Input Power
Accepts an Analog Voltage Speed Reference
Three Internally Set Speeds
Compact Design
Easy Operation

Applications with Specialized Motors
Multi-Pole Motor
Because the rated current will differ from a standard motor, be sure to check the maximum current when selecting a drive.
Always stop the motor before switching between the number of motor poles. If a regen overvoltage (oV) fault occurs or if
overcurrent protection (oC) is triggered, the motor will coast to stop.
Submersible Motor
Because motor rated current is greater than a standard motor, select the drive capacity accordingly. Be sure to use a large
enough gauge motor cable to avoid decreasing the maximum torque level on account of voltage drop caused by a long motor
cable.
