GE FANUC SERIES 90-30 PLC Digital I/O Module IC697MDL341 FACTORY SEALED

GE FANUC SERIES 90-30 PLC Digital I/O Module IC697MDL341 FACTORY SEALED



Product Description:

GE Fanuc Discrete input module for 90 - 30 series PLC offers 16 input points with one common power input terminal. It requires an AC power source for convenient operation. Module has LED indicators at the top to offer ON/OFF status of each point. Module has circuit wiring information on the surface towards the inside and circuit identification information on the outside surface. Module has a voltage rating of 120 VAC at 50/60 Hz, 0 - 132 VAC at 50/60 Hz, input current rating of 12 milli-Amps and a power rating of 90 milli-Amps at 5 VDC. It has a maximum ON response time of 30 milli-seconds and maximum OFF response time of 45 milli-seconds. Module is compatible with input devices such as pushbuttons, limit switches and electronic proximity switches. Input/output module provides the interface between the PLC and external input devices such as proximity sensors, push buttons, switches and BCD thumbwheels. It supports different voltage ranges, types, current capacity, isolation and response time to meet your application.




Product Details:

Input modules provide the interface between the PLC and external input devices such as proximity sensors, push buttons, switches and BCD thumbwheels. Output modules provide the interface between the PLC and external output devices such as contactors, interposing relays, BCD displays and indicator lamps. This module requires an AC power source, it cannot be used with a DC power source.





Product Summary:

• Rated Voltage: 120 Volts AC, 60 Hz Sinusoidal

• Inputs Per Module: 16 Individually Isolated

• On-state Voltage: 75 volts to 132 volts, 60 Hz sinusoidal

• Off-state Voltage: 0 to 20 volts, 60 Hz sinusoidal

• On-state Current: 8mA to 15 mA

• Description: 120 VAC Isolated Input 16-PT

• Off-state Current: 0 to 4mA (2.2mA minimum at 25V input)

• Filter Delay Time: 20ms typical

• Current Req. from 5V Bus: 0.25 amps

• VME: System designed to support the VME standard C.1

• Features: 16 isolated points, 20 ms input filter, proximity switch compatible

• Product Description: The 120 Volt AC Isolated Input Module provides 16 input points which are isolated. This allows each point to be used on a different phase of the AC supply. The input is reactive (resistor/capacitor input) with current-voltage characteristics which meet IEC standard (type 2). The input characteristics are compatible with a large range of available proximity switches. LED indicators which give the ON-OFF status of each point on the logic (PLC) side of the circuit are included at the top of the module. The module is mechanically keyed to allow correct replacement with a similar type in the field. I/O references are user configurable without the use of jumpers or DIP switches on the module.
