Industrial AC Servo Motor Mitsubishi HA200CBS with Absolute Encoder NEW ORIGINAL

Superb delivery a great product, perfect communication as well !! A++++

—— Carlos

Great deal. Fast shipping and good service.Recommended !!!!!!!!!

—— Gita

I'm Online Chat Now

Industrial AC Servo Motor Mitsubishi HA200CBS with Absolute Encoder NEW ORIGINAL

Large Image :  Industrial AC Servo Motor Mitsubishi HA200CBS with Absolute Encoder NEW ORIGINAL

Product Details:

Place of Origin: Japan
Brand Name: Mitsubishi
Certification: CE
Model Number: HA200CBS

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Contact us
Packaging Details: New Original Box
Delivery Time: In Stock
Payment Terms: T/T / Paypal
Supply Ability: 50
Detailed Product Description
Category: Industiral Servo Motor Model: HA200CBS
Rated Output Power: 3.5KW Rated Speed: 2000r/min
Series: HA Series Brand: Mitsubishi
High Light:

ewing machine servo motor

,

electric servo motor

Industrial AC Servo Motor Mitsubishi HA200CBS with Absolute Encoder NEW ORIGINAL



Specification of Industrial Servo Motor HA200CBS



Description HA200CBS is a Motors-AC Servo produced by Mitsubishi
Motor Series HA
Motor Power Class 3.5kW N-Type (2000 r/min); 2.0kW L-Type (2000 r/min)
Motor Type Conventional motor
Main Circuit Specification Main circuit cannon connector type
Electromagnetic Brake Specification With electromagnetic brake
Shaft Specification Straight shaft; Tapered shaft (HA40, 43, 80, 83 only)(no symbol)
Shaft End Specification Shaft end with oil seal
Option 1 Other
Option 2 IP54


Similiar Industrial Servo Motors:

HA200B-S
HA200C
HA200CB
HA200CB-S
HA200C-S
HA200NC-S
HA103NC-S
HA100NCB-S
HA100NC-S
HA100CB-S
HA100C
HA100C-KN
HA100B-S
HA100B-SSD7
HA100C
HA100CB-S
HA100C-KN
HA100C-S


INSTALLTION of Protection from oil and water

(1) Next, the servo motor is not waterproof (IP44). Do not subject the servo motor to oil and water.
Especially for the HC-MF / HC-KF / HC-AQ / HC-KFS / HC-MFS and HA-FF series, do not subject the
shaft-through portion to oil.

(2) When the gear box is mounted horizontally, the oil level in the gear box should always be lower than
the oil seal lip on the servo motor shaft. If it is higher than the oil seal lip, oil will enter the servo motor, leading to a fault. The HC-MF / HC-KF / HC-AQ / HC-MFS and HC-KFS series servo motor is not equipped with an oil seal and cannot be used with the gear box as described above. Oil should be shut off on the gear box side.

(3) When installing the servo motor horizontally, face the power cable and encoder cable downward. When installing the servo motor vertically or obliquely, provide a trap for the cable.

(4) Do not use the servo motor with its cable soaked in oil or water. (Figure on the right)

(5) When the servo motor is to be installed with the shaft end at top, provide measures so that it is not
exposed to oil and water entering from the machine side, gear box, etc.

(6) If the servo motor is exposed to oil such as coolant, the sealant, packing, cable and others may be
affected depending on the oil type.

(7) In the environment where the servo motor is exposed to oil mist, oil, water, grease and/or like, the
servo motor of the standard specifications may not be usable. Contact us.

(8) In the case of the servo motor with oil seal, the oil seal may sound during operation. It poses no
problems in function.


Servo amplifier model

MR-H60A(N)
MR-H100A(N)
MR-H200A(N)
MR-H350A(N)
MR-H500A(N)
MR-H700A(N)


Servo amplifier model *20 *21

MR-J3-60A
MR-J3-100A
MR-J3-200A
MR-J3-350A
MR-J3-500A
MR-J3-700A


HC-KF Series Servo Motor


HC-KF13
HC-KF13B
HC-KF13K
HC-KF13D
HC-KF13BK
HC-KF13G1
HC-KF13G2
HC-MF13
HC-MF13B
HC-MF13BD-S15
HC-MF13BG1-UE
HC-MF13D
HC-MF13D-S2

HC-MF23
HC-MF23BK
HC-MF23BK-UE
HC-MF23G1-UE
HC-MF23-S15
HC-MF23-UE



HA-FE Series AC SERVO MOTOR

HA-FE63
HA-FE63B
HA-FE63G
HA-FH13
HA-FH053
HA-FH23
HA-FH33
HA-FH43
HA-FH63
HA-FH053B

HC-KFS series Motors

HC-KFS13
HC-KFS23
HC-KFS43
HC-KFS73
HC-KFS13B
HC-KFS23B
HC-KFS43B
HC-KFS053B
HC-KFS73B
HC-KFS13K
HC-KFS23K
HC-KFS43K
HC-KFS053K
HC-KFS73K
HC-KFS13BK
HC-KFS23BK
HC-KFS43BK
HC-KFS053BK




Similar Products

HC-MFS053 HC-KFS053 HC-MFS13 HC-KFS13 HC-MFS053B HC-KFS053B
HC-MFS13B HC-KFS13B HC-MFS053K HC-KFS053K HC-MFS13K HC-KFS13K
HC-MFS053BK HC-KFS053BK HC-MFS13BK HC-KFS13BK HC-MFS23 HC-KFS23
HC-MFS43 HC-KFS43 HC-MFS23B HC-KFS23B HC-MFS43B HC-KFS43B
HC-MFS23K HC-KFS23K HC-MFS43K HC-KFS43K HC-MFS23BK HC-KFS23BK
HC-MFS43BK HC-KFS43BK HC-MFS73 HC-KFS73 HC-MFS73B HC-KFS73B
HC-MFS73K HC-KFS73K HC-MFS73BK HC-KFS73BK HC-SFS81 HC-SFS121
HC-SFS201 HC-SFS301 HC-SFS52 HC-SFS102 HC-SFS152 HC-SFS202
HC-SFS52B HC-SFS102B HC-SFS152B HC-SFS202B HC-SFS52K HC-SFS102K
HC-SFS152K HC-SFS202K HC-SFS52BK HC-SFS102BK HC-SFS152BK HC-SFS202BK
HC-SFS352 HC-SFS502 HC-SFS702 HC-SFS352B HC-SFS502B HC-SFS702B
HC-SFS353 HC-SFS352K HC-SFS502K HC-SFS702K HC-RFS353 HC-RFS103
HC-RFS153 HC-RFS203 HC-RFS353 HC-SFS53 HC-SFS103 HC-SFS153
HC-SFS203 HC-KFS13 HC-KFS13B HC-MF73-S15 HC-MF053 HC-KFSP3





Good Service in WTL:


> We offer high quality, fast delivery, competitive price for Servo Drives and Motors.
> Please send your RFQ to get the latest price.
> Normally, we will ship the items in 1-2 weeks after receive the payment.
> We can ship to you by UPS/DHL//EMS/Fedex. Please contact us and we will use your preferred ways.
> We have a large stock and the prices are variable, so sometimes the prices we post are not accurate. If needed, please contact us for specific prices.



Liability:

WTL is not liable for any personal injury or property damage resulting from the use of this equipment. It is
buyer's responsibility as to the safe handling & operation of this equipment and to verify equipment is
compliance to their machinery.
