Mitsubishi Universal model QJ71FL71-B5-F01 Redundant Power Supply Module

Input points: 16 points.
Input voltage and current: 6mA DC24V.
Response time: 0/0.1/0.2/0.4/0.6/1ms.
16 point /1 a public side.
Common anode.
18 point terminal station.
Easy connection programming tool via ethernet.
Programming tools (Works2 GX, Developer GX) and CPU direct connection (1 to 1),
No need to carry out the IP address settings MITSUBISHI QJ71FL71-B2-F01. And there is no need to select the cable, the straight line and the cross line can be used QJ71FL71-B2-F01
Therefore, this connection method and the use of USB, can easily communicate with the CPU,
Even the operators are not familiar with the network settings can easily establish a connection.
A variety of modules with excellent performance,
Meet the needs of various control from analog to location MITSUBISHI QJ71FL71-B2-F01.
Q series module products include a variety of types of I/O, analog and positioning function module.
Can fully meet the switch, sensor, such as the input and output, temperature, weight, flow and motor, drive control,
As well as the requirements of high-precision control of the positioning of the industry, the control needs of various fields.
Can also be used in combination with the CPU module to achieve appropriate control MITSUBISHI QJ71FL71-B2-F01.
Continue to go beyond, to climb the peak of Q series.
Strengthen security function.
Can be set up to 32 characters of the file password.
In addition to the English letters, numbers, but also the use of special characters,
To further enhance the security of the password.
In addition, only pre registered devices are allowed to access CPU,
To intercept unauthorized access to unauthorized users.
Therefore, it is important to prevent the outflow of important program assets and protect intellectual property rights.Input / output points: 4096 points.
Number of input and output elements: 8192.
Program capacity: 30 K step.
Processing speed: 34ns.
Program memory capacity: 144 KB.
Built in RS232 communication port.
Support installed memory card.
For A mode only.
Enhance the basic performance.
CPU''s built-in soft element memory capacity increases to up to 60K.
To increase the control, quality management data can also be processed at high speed.
Convenient processing of large capacity data.
In the past can not achieve the standard RAM and SRAM card file register area of continuous access,
The boundary of each area should be considered in programming.
The SRAM 8MB extension card is installed in the high speed universal QCPU,
Standard RAM can be used as a continuous file register,
Capacity up to 4736K words, thus simplifying the programming.
Thus, even if the memory space of the soft element is insufficient,
Can also be installed by the expansion of SRAM card, easy to extend the file register area.
The address register is extended to 32 bits, which can be programmed to go beyond the tradditional 32K word,
And to achieve the extension to the file register to all regions of the file register QJ71FL71-B2-F01.
In addition, the processing speed of the index modification plays an important role in the efficient operation of structured daata (array),
The speed has been improved QJ71FL71-B2-F01.
When the index is used to modify the program repeatedly (e.g. from FOR to NEXT), the scan time can be reduced.
