12 -253 VAC IC220PWR201 GE Power Terminal 230 VAC IC220TBK204
Power Terminals
Power Terminal modules supply power to the main circuit (UM) . In addition, this module can be
used to supply power for a segment circuit (Us) .
An I/O Network Interface Unit connects VersaPoint I/O modules to a host PLC or computer via a
variety of networks, which makes it easy to include VersaPoint I/O in PROFIBUS-DP, Ethernet or
DeviceNet installations . Together, the NIU is capable of handling up to 63 modules in one node .
| IC220PWR001 | IC220PWR002 | IC220PWR003 | IC220PWR101 | IC220PWR201 | |
| Product Name | Power Terminal 24 VDC |
Power Terminal Fused 24 VDC |
Power Terminal Fused with Diagnostics 24 VDC |
Power Terminal 120 VAC |
Power Terminal 230 VAC |
| Lifecycle Status | Active | Active | Active | Active | Active |
| Input Voltage | 24 VDC | 24 VDC | 24 VDC | 120 VAC | 120 VAC |
| Input Voltage Range | 19 .2 - 30 VDC | 19 .2 - 30 VDC | 19 .2 - 30 VDC | 108 -135 VAC | 12 -253 VAC |
| Maximum Current | 8 Amps | 8 Amps | 6 .3 Amps | 8 Amps | 8 Amps |
| Overload/Short Circuit in Segment Circuit |
No | Fuse | Fuse | No | No |
| Surge Voltage/Over Voltage | Yes, suppressor diode for voltage limitation |
Yes, suppressor diode for voltage limitation |
Yes, suppressor diode for voltage limitation |
Yes, VAR 275 VAC | Yes, VAR 275 VAC |
| Polarity Reversal | Yes, diode connected in parallel as protection against polarity reversal |
Yes, diode connected in parallel as protection against polarity reversal |
Yes, diode connected in parallel as protection against polarity reversal |
N/A | N/A |
| Current Consumption from Local Bus UL (mA) |
N/A | N/A | 25 mA, maximum | N/A | N/A |
| LED Indicators | 24 VDC Voltage Present |
24 VDC Voltage Present and Blown Fuse |
Bus Diagnostics and Blown Fuse |
120 VAC supply Present |
230 VAC supply Present |
| Required Terminal Strip | (1) IC220TBK087 (Contains 10 strips) |
(1) IC220TBK087 (Contains 10 strips) |
(1) IC220TBK087 (Contains 10 strips) |
(1) IC220TBK204 | (1) IC220TBK204 |
