CONTROL TECHNIQUES SKA1100037 variable frequency drive Commander SK 0.37 kW output

: Large Image : CONTROL TECHNIQUES SKA1100037 variable frequency drive Commander SK 0.37 kW output

Product Details:

Place of Origin:	CHINA
Brand Name:	Emerson CONTROL TECHNIQUES
Certification:	CE
Model Number:	SKA1100037

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Contact us
Packaging Details:	New Original Box
Delivery Time:	2-3 work days
Payment Terms:	T/T / Paypal
Supply Ability:	50

Contact Now

Detailed Product Description

Model:	SKA1100037	Type:	AC Inverter DRIVE
Series:	Commander SK	Rated Power:	0.37 KW
Voltage:	100/120 VAC	Horsepower Rating:	5HP
Weight:	6kg	Brand:	Control Techniques
High Light:	electric servo drive , ac servo pack

CONTROL TECHNIQUES SKA1100037 variable frequency drive Commander SK 0.37 kW output

Description

Commander SK Series General Purpose AC Drive -- SKA1100037

Commander SK, .5 HP, 2.2 amp, 100/120 VAC, .37 kW output

Commander SK is a compact, easy-to-use general purpose drive that simplifies the installation and configuration of the drive to save time, yet has the performance and depth of functions required to solve more complex applications challenges, delivering superior value and motor control. All drives in this Commander SK AC drive line is conformal coated as a standard feature.

Specifications

Product Category:Motor Controllers

Product:Speed Controller; Variable Speed

Axes:1.0

Motor / System:Induction; Sensorless Vector

Electrical Specifications: AC Input 100 to 120 volts

Phase: Single Phase

Unidrive M: compatibility with Commander SK and Unidrive SP

Mechanical
• Compatible physical dimensions, weights and surface mount footprint.
• When retrofitting surface mount drives, existing mounting holes can be reused-negating the need for additional drilling. Mounting holes are in the same place or retrofit kits are available.

Electrical
• Power and control wiring adopt the same philosophy as Commander SK and Unidrive SP.

Parameters

• The same menu and parameter structure is adopted by Unidrive M.
• Parameters can be transferred from Unidrive SP to Unidrive M using a Smartcard.
• Unidrive M Connect can be used to transfer parameters from Unidrive SP and Commander SK to Unidrive M.

Software programs

• The SI-Applications Plus option module can compile SyPTPro programs for Unidrive M.

Commander SK AC Inverter

SKA1100025	SKA1100037	SKB1100075	SKB1100110	SKA1200025	SKA1200037	SKA1200055
SKBD200110	SKBD200150	SKCD200220	SKDD200300	SKD3200400	SKB3400037	SKB3400055
SKB3400110	SKB3400150	SKB3400220	SKB3400300	SKB3400400	SKB3400550	SKB3400750
SKA1200075	SKB3400075	SK3201	SK3202	SK4201	SK4202	SK4203
SK2402	SK2403	SK2404	SK3401	SK3402	SK3403	SK4401
SK4403	SK5401	SK5402	SK6401	SK6402	SK3501	SK3502
SK3504	SK3505	SK3506	SK3507	SK4601	SK4602	SK4603
SK4605	SK4606	SK5601	SK5602	SK6601	SK6602	SK6602
SK2401	SK4402	SK2201	SK2202	SK2203	SK3503	SK4604

SP Drives

SP1201	SP1202	SP1203	SP1204	SP2201	SP2202	SP2203	SP3201
SP3202	SP4201	SP4202	SP4203	SP5201	SP5202	SP3501	SP3502
SP0401	SP0402	SP0403	SP0404	SP0405	SP1401	SP1402	SP1403
SP1404	SP1405	SP1406	SP2201	SP2202	SP2401	SP2402	SP2403
SP2404	SP3401	SP3402	SP3403	SP4401	SP4402	SP4403	SP5401
SP5402	SP5403	SP6401	SP6402	SP3505	ES2401	ES2402	ES2403
SP3503	SP3504	SP3506	SP4601	SP4602	SP4603	SP4604	SP4605
SP4606	SP5601	SP5602	SP6601	SP6602

UNI Drives:

UNI1201	UNI1202	UNI1203	UNI1204	UNI1205	UNI2201	UNI2202	UNI2203
UNI3201	UNI3202	UNI3203	UNI3204	UNI1401	UNI1402	UNI1403	UNI1404
UNI1405	UNI2401	UNI2402	UNI2403	UNI3401	UNI3402	UNI3403	UNI3404
UNI3405	UNI4401	UNI4402	UNI4403	UNI4404	UNI4405	UNI5401	SP5402
