New Pro-face GP2000 Series GP2400-TC41-24V TOUCH SCREEN GRAPHIC PANEL

New Pro-face GP2000 Series GP2400-TC41-24V TOUCH SCREEN GRAPHIC PANEL

Product Description
XYCOM
PROFACE
GP2600-TC41-24V-W30
GP2600TC4124VW30
DISCONTINUED BY MANUFACTURER
OPERATOR INTERFACE
QUICKPANEL
12.1 INCHES
TFT COLOR LCD
24 VDC
ETHERNET
CF CARD

System Design

• Do not create GP touch panel switches that could possibly endanger the safety of equipmentand personnel. Damage to the GP, its I/O unit(s), cable(s), and other related equipment cancause an output signal to remain continuously ON or OFF and possibly cause a major acci-dent. Therefore, design all monitoring circuits using limit switches, etc. to detect incorrectdevice movement. To prevent accidents related to incorrect signal output or operation, de-sign all switches used to control vital machine operations so they are operated via a separatecontrol system.

• Do not create switches used to control machine safety operations, such as an emergency stopswitch, as a GP touch screen icon. Be sure to install these switches as separate hardwareswitches, otherwise severe bodily injury or equipment damage can occur.

• Please design your system so that equipment will not malfunction due to a communicationfault between the GP and its host controller. This is to prevent any possibility of bodily injuryor material damage

.• The GP is not appropriate for use with aircraft control devices, aerospace equipment, centraltrunk data transmission (communication) devices, nuclear power control devices, or medicallife support equipment, due to these devices' inherent requirements of extremely high levelsof safety and reliability.

• When using the GP with transportation vehicles (trains, cars and ships), disaster and crimeprevention devices, various types of safety equipment, non-life support related medicaldevices, etc. redundant and/or failsafe system designs should be used to ensure the properdegree of reliability and safety.

• Do not use the GP unit as a warning device for critical alarms that can cause serious operatorinjury, machine damage or production stoppage. Critical alarm indicators and their control/activator units must be designed using stand-alone hardware and/or mechanical interlocks.

• After the GP's backlight burns out, unlike the GP's "Standby Mode", the touch panel is stillactive. If the operator fails to notice that the backlight is burned out and touches the panel, apotentially dangerous machine miss-operation can occur. Therefore, do not use GP touchswitches for the control of any equipment safety mechanisms, such as Emergency Stopswitches, etc. that protect humans and equipment from injury and damage. If your GP'sbacklight suddenly turns OFF, use the following steps to determine if the backlight is actu-ally burned out.1) If your GP is not set to "Standby Mode" and the screen has gone blank, your backlight isburned out.2) Or, if your GP is set to Standby Mode, but touching the screen does not cause the displayto reappear, your backlight is burned out.Also, to prevent accidental machine miss-operation, Digital suggests you use the GP's built-in "USE TOUCH PANEL AFTER BACKLIGHT BURNOUT" feature, that will automati-cally detect a burnout and disable the touch screen.Installation

• High voltage runs through the GP. Except for replacing the backlight, never disassemble theGP, otherwise an electric shock can occur.

• Do not modify the GP unit. Doing so may cause a fire or an electric shock.

• Do not use the GP in an environment where flammable gasses are present, since operatingthe GP may cause an explosion.

Wiring

• To prevent an electric shock, be sure to confirm that the GP's power cord is not connected tothe main power when connecting any cords, cables or lines to the GP.

• Be sure to replace the GP's plastic terminal block cover after wiring is completed, sinceoperating the GP without the cover may lead to an electric shock

• Do not use power beyond the GP's specified voltage range. Doing so may cause a fire or anelectric shock.Maintenance

• The GP uses a lithium battery for backing up its internal clock data. If the battery is incor-rectly replaced, the battery may explode. To prevent this, please do not replace the batteryyourself. When the battery needs to be replaced, please contact your local GP distributor
