Technical Specifications for IC693MDL742

Technical Specifications for IC693MDL742

Brand GE Fanuc
Series Series 90-30
Manufacturer GE Fanuc; Emerson Automation (Current)
Manufacturer GE Fanuc
Series Series 90-30
Part Number IC693MDL742
Product Description Discrete output module
Part Number IC693MDL742
Product type Digital I/O
No of Channels Sixteen (16)
Compatibility GE Fanuc 90-30
No. of groups Two (2)
Product Description Discrete output module with integrated Electronic Short Circuit Protection (ESCP)
Rated voltage 12/ 24 Volts DC
No. of channels per group Eight (8)
No. of output groups Two (2)
Channels per group Eight (8)
Isolation: 1500 volts between field side and logic side; 500 Volts between groups
Peak module current draw 130 milliamps

Output voltage range 12-24 VDC with (+ 20%, -15%)
Output signal range 12 to 24 volts DC (+20%, –15%)
Maximum off response time 2 milliseconds
Nominal Input voltage 12 / 24 VDC
Maximum on response time 2 milliseconds
Nominal output voltage 12 / 24 VDC
Output current 1.0 Amperes per point; 4.0 Amperes per group at 50 Degrees Celsius; 3.0 Amperes per group at 60 Degrees Celsius
Peak output voltage drop 1.2 Volts
Off response time, maximum 2 ms
Current draw 130 mA (all outputs active)
Relative humidity 5 to 95%
Output Voltage Drop 1.2 volts, maximum
On response time, maximum 2 ms
Product Lifecycle Status* Discontinued/Obsolete
Off-state Leakage 1 mA maximum
Off response time, maximums 2 ms
Product Lifecycle Status Discontinued/Obsolete

About IC693MDL742

The IC693MDL742 is a Series 90-30 component module. This module is specifically a discrete output module with integral Electronic Short Circuit Protection (ESCP). This module supports Positive logic wiring configuration and delivers an output voltage range of 12-24 VDC, +20%, -15%. Similarly, it has output current ratings of 1 Ampere per point, maximum; Maximum of 4 Amperes per group when operated at 50 Degree Celsius, and 3 Amperes per group at 60 Degree Celsius. The IC693MDL742 is installed to a Series 90-30 Baseplate. It occupies a single slot and may be installed to any vacant slot except the Power Supply, CPU, and specialty module designated mounting location. There is no specific limit to the number of allowed module instances. The actual limit depends on the supported I/O capacity of the host processor, memory size, and the available baseplate slot. It can be used to energize loads such as motor starters, solenoid-actuated devices, indicating lamps, relays, and similar devices. It comes with individual channel indicators that depict the energization state of the output channel. The embedded Electronic Short Circuit Protection (ESCP) of this module is designed to monitor the common signal of each group. If a short circuit is detected, the “F” LED energizes signifying short-circuit condition. Aside from status indication, the ESCP protects the circuit board from damage. This module has a backplane power consumption of 130 mA when all outputs are energized. The output channels have a typical response time of 2 ms, maximum. This module generates an inrush current of 5.2 Amperes with a duration of 10 ms while the off-state leakage current is a maximum of 1 mA.

The GE Fanuc IC693MDL742 module is a 12 to 24 Volts DC positive logic Electronic Short Circuit Protection (ESCP) output module. The IC693MDL742 module provides 16 output points arranged in 2 groups of 8. Each group has a common power output terminal. The common signal for each group is monitored electronically. When a short circuit occurs, a red LED on the IC693MDL742 module switches on and the outputs in that group are switched off. This red LED is placed between the rows of green LEDs which provide status updates for all of the individual output points. The short circuit protection feature on the IC693MDL742 module does not protect the individual output points from exceeding their current rating, however, it will protect the module board when a short circuit occurs.

The 12 to 24 Volts DC module power supply needs to be removed to reset the electronic short circuit protection in the IC693MDL742 module after it has been triggered. There are 2 short circuit protection circuits on the module, one for each group of output points. The C693MDL742 module is designed for positive logic characteristics. The output current ratings are 1 Amp per point, 4 Amps per group at 50 degrees Celsius, and 3 Amps per group at 60 degrees Celsius. The maximum current consumption of the IC693MDL742 module is 130 milliamps. The inrush current for the module is 5.2 Amps for 10 milliseconds duration. The maximum output voltage drop is 1.2 Volts. The maximum value for both the off response and on response times is 2 milliseconds. The relative humidity (non-condensing) around the module should be maintained between 5 and 95%.
