Product Details:
Payment & Shipping Terms:
|
| Range Of Product: | Modicon Quantum Automation Platform | Country Of Origin: | France |
|---|---|---|---|
| Brand: | Schneider | PN: | 140EIA92100 |
| Condition: | Brand New | Type: | QUANTUM PROCESSOR |
| High Light: | quantum unity processor,modicon quantum cpu |
||
| range of product |
Modicon Quantum automation platform
|
|
|---|---|---|
| product or component type |
AS-Interface master module
|
| range compatibility |
AS-Interface cabling system
|
|
|---|---|---|
| AS-i version |
V1
|
|
| actuator sensor interface profile [AS-i] |
M2
|
|
| addressing |
Standard
|
|
| maximum cycle time |
5 ms
|
|
| bus length |
0.00…328.08 ft (0…100 m) without repeater
|
|
| discrete input number |
124
|
|
| discrete output number |
124
|
|
| number of slave |
31
|
|
| number of module per PLC |
2 per Quantum PLC distributed drop
4 per Quantum PLC local drop 4 per Quantum PLC remote drop |
|
| supply |
Via AS-Interface line
|
|
| [Us] rated supply voltage |
30 V DC
|
|
| AS-i cabling system cycle time |
156 x (n + 1) µs 31
156 x (n + 2) µs |
|
| transmission rate |
167 kbit/s
|
|
| reverse polarity protection |
Internal
|
|
| local signalling |
Slave addresses and state of slave I/O bits 32 LEDs
|
|
| electrical connection |
1 male connector SUB-D 3 pins AS-Interface link
|
|
| current consumption |
<= 100 mA
|
|
| typical current consumption |
60 mA 30 V DC
|
|
| marking |
CE
|
|
| net weight |
0.99 lb(US) (0.45 kg)
|
| IP degree of protection |
IP20
|
|
|---|---|---|
| ambient air temperature for operation |
32…140 °F (0…60 °C)
|
|
| product certifications |
FM
CSA GOST C-Tick UL |
| Category |
18155-QUANTUM I/O & POWER SUPPLIES
|
|
|---|---|---|
| Discount Schedule |
PC21
|
|
| GTIN |
00785901785286
|
|
| Package weight(Lbs) |
1.04 lb(US) (0.472 kg)
|
|
| Returnability |
No
|
|
| Country of origin |
FR
|
| Sustainable offer status |
Green Premium product
|
|
|---|---|---|
| California proposition 65 |
WARNING: This product can expose you to chemicals including: Lead and lead compounds which is known to the State of California to cause cancer and birth defects or other reproductive harm.For more information go to www.p65warnings.ca.gov
|
|
| EU RoHS Directive |
Pro-active compliance (Product out of EU RoHS legal scope)
EU RoHS Declaration |
|
| Environmental Disclosure | ||
| Circularity Profile |
