Product Details:
Payment & Shipping Terms:
|
| Range Of Product: | Modicon Premium | Country Of Origin: | France |
|---|---|---|---|
| Brand: | Schneider | PN: | TSXASZ200 |
| Output Number: | 8 | Conversion Time: | 5 Ms |
| Warranty: | 12 Months | ||
| High Light: | modicon quantum processor,modicon quantum cpu |
||
| range of product |
Modicon Premium Automation platform
|
|
|---|---|---|
| product or component type |
Analog output module
|
|
| analogue output number |
8
|
|
| analogue output type |
Current: 0...20 mA
Current: 4...20 mA Voltage: +/- 10 V |
|
| analog/digital conversion |
13 bits + sign +/- 10 V
13 bits 0...20 mA 13 bits 4...20 mA |
| conversion time |
5 ms
|
|
|---|---|---|
| measurement resolution |
1.28 mV +/- 10 V
2.56 µA 0...20 mA 2.56 µA 4...20 mA |
|
| electrical connection |
1 SUB-D 25 connector
|
|
| measurement error |
0.14 % of full scale +/- 10 V 25 °C
0.21 % of full scale 0...20 mA 25 °C 0.21 % of full scale 4...20 mA 25 °C 0.28 % of full scale +/- 10 V 0...60 °C 0.52 % of full scale 0...20 mA 0...60 °C 0.52 % of full scale 4...20 mA 0...60 °C |
|
| isolation between channels |
Common point
|
|
| isolation between channels and bus |
1000 Vrms
|
|
| isolation between channels and ground |
1000 Vrms
|
|
| protection type |
Short-circuit protection
Overload protection |
|
| output voltage limits |
<= 30 V
|
|
| load impedance ohmic |
< 600 Ohm 0...20 mA
< 600 Ohm 4...20 mA > 1000 Ohm +/- 10 V |
|
| maximum load inductance |
300 µH
|
|
| maximum load capacitance |
0.1 µF
|
|
| marking |
CE
|
|
| current consumption |
200 mA at 5 V DC
300 mA at 24 V DC |
|
| module format |
Standard
|
|
| terminals description PLC n°1 |
(16)OUT_ANA_CUR#1
(13)IN_ANA_STD# (24)OUT_ANA_VOLT#7 (8)OUT_ANA_CUR#4 (20)OUT_ANA_COM#4 (1)OUT_ANA_VOLT#0 (17)OUT_ANA_COM#2 (4)OUT_ANA_VOLT#2 (9)OUT_ANA_COM#5 (11)OUT_ANA_CUR#6 (19)OUT_ANA_CUR#3 PW_NEG# (25)OUT_ANA_CUR#7 (3)OUT_ANA_COM#1 (12)OUT_ANA_COM#7 (5)OUT_ANA_CUR#2 (6)OUT_ANA_COM#3 (15)OUT_ANA_VOLT#1 (18)OUT_ANA_VOLT#3 (22)OUT_ANA_CUR#5 (10)OUT_ANA_VOLT#6 PW_POS# (14)OUT_ANA_COM#0 (23)OUT_ANA_COM#6 (2)OUT_ANA_CUR#0 (7)OUT_ANA_VOLT#4 (21)OUT_ANA_VOLT#5 |
| standards |
93/68/EEC
CSA C22.2 No 213 Class I Division 2 Group A CSA C22.2 No 142 73/23/EEC CSA C22.2 No 213 Class I Division 2 Group B 89/336/EEC CSA C22.2 No 213 Class I Division 2 Group D UL 508 IEC 61131-2 92/31/EEC CSA C22.2 No 213 Class I Division 2 Group C |
|
|---|---|---|
| product certifications |
BV
RINA DNV LR ABS RMRS GL |
|
| ambient air temperature for operation |
0…60 °C
|
|
| ambient air temperature for storage |
-25…70 °C
|
|
| relative humidity |
10…95 % without condensation for operation
5…95 % without condensation for storage |
|
| operating altitude |
0...2000 m
|
|
| protective treatment |
TC
|
|
| IP degree of protection |
IP20
|
|
| pollution degree |
2
|
| Warranty |
18 months
|
|---|
