Product Details:
Payment & Shipping Terms:
|
| Brand: | AB | Type: | PLC |
|---|---|---|---|
| Model: | 1756-A10 | Origin Of Country: | USA |
| Series: | SLC 500 | Output Types:: | N.O. Relay Contact |
| Lead Time: | 3days | Warranty: | 1 Year |
| Highlight: | ethernet plc controllers,industrial automation using plc |
||
ALLEN BRADLEY ControlLogix plc 1756-A10 ControlLogix 10 Slots Chassis
Description:
AB 1756-A10 10 Slot ControlLogix Chassis. The 1756-A10 chassis backplane provides a high-speed communication path between modules and distributes power to each of the modules within the chassis. Any ControlLogix module can be placed into any slot. Slot filler modules (1756-N2) are required to fill empty slots.
The 1756-A10 ControlLogix chassis are designed for horizontal mounting only. Number of Slots: 10; Backplane current, chassis/slot max @ 1.2V DC: 1.5 A/1.5 A; Backplane current, chassis/slot max @ 3.3V DC: 4 A/4 A; Backplane current, chassis/slot max @ 5.1V DC: 15 A/6 A; Backplane current, chassis/slot max @ 24V DC: 2.8 A/2.8 A; Power dissipation: 6.1 BTU/hr; Power consumption: 1.8 W. Dimensions (WxHxD): 483 x 169 x 145 mm (19.0 x 6.65 x 5.71 in.); Cabinet size (WxHxD), min: 762x 507 x 203 mm (30 x 20 x 8 in.); Weight, approx.: 1.45 kg (3.2 lb).
other model number
| 1756-A10 | 1756-L71 | 1756-IF8 |
| 1756-A13 | 1756-L72 | 1756-IF8I |
| 1756-A17 | 1756-L73 | 1756-IG16 |
| 1756-A4 | 1756-N2 | 1756-IT16 |
| 1756-A7 | 1756-OA16 | 1756-L61 |
| 1756-CN2R | 1756-OA8 | 1756-L62 |
| 1756-CN B | 1756-OB16D | 1756-L63 |
| 1756-CN BR | 1756-OB16E | 1756-L64 |
| 1756-DNB | 1756-OB16I | 1756-L65 |
| 1756-EN2T | 1756-OB32 | 1756-PB75 |
| 1756-ENBT | 1756-OB8 | 1756-RM2 |
| 1756-HSC | 1756-OF4 | 1756-IF16 |
| 1756-IA16 | 1756-OF6CI | 1756-IF6I |
| 1756-IA16I | 1756-OF6VI | 1756-PA75R |
| 1756-IA32 | 1756-OF8 | 1756-PB72 |
| 1756-IA8D | 1756-OG16 | 1756-IB32 |
| 1756-IB16 | 1756-OW16I | 1756-IC16 |
| 1756-IB16D | 1756-PA72 | |
| 1756-IB16I | 1756-PA75 |
