AJ65SBTB1-8D Mitsubishi Redundant Power Supply Module 100 To 240 V AC

Mitsubishi Universal model AJ65SBTB1-8D Redundant Power Supply Module

AJ65SBTB1-8D Description

AJ65SBTB1-8D Features

• CC-Link Network Integration:​ Functions seamlessly as a remote device station on the CC-Link network, allowing for centralized control from a master PLC over a high-speed, noise-resistant communication link.
• Compact, High-Density Output:​ Provides 16 output points in a space-saving module, ideal for remote control panels with multiple devices.
• Sourcing (PNP) Output:​ The 24V DC sourcing (PNP) transistor output type is standard for connecting to a wide range of industrial actuators and devices that require a positive voltage supply for operation.
• Clear Diagnostics:​ Equipped with LEDs for power, network status, and individual point output status (ON/OFF), enabling quick visual confirmation of operation and simplifying troubleshooting.
• Easy Installation & Wiring:​ Features a removable terminal block for convenient screw-terminal wiring and is designed for standard DIN rail mounting, facilitating rapid deployment in the field.
• Long-Distance Control:​ Supports the extended transmission distances of the CC-Link network (up to 1.2 km at 156kbps), allowing remote control of equipment spread across a large facility.

AJ65SBTB1-8D Material & Primary Applications

• Material:​ The housing is constructed from robust, flame-retardant engineering plastic. Internal circuits utilize industrial-grade transistors and components, with terminals designed for reliable screw connections.
• Primary Applications:
  • Distributed control of solenoid valves in pneumatic/hydraulic systems.
  • Operating indicator lights, alarms, and control relays in remote panels.
  • Conveyor line motor starters and diverter controls.
  • Packaging machinery and assembly station actuators.
  • Any application requiring remote digital output control as part of a CC-Link network.

AJ65SBTB1-8D Important Parameters
