Product Details:
Payment & Shipping Terms:
|
| Range Of Product: | Modicon Quantum Automation Platform | Product Or Component Type: | Analogue Input Module |
|---|---|---|---|
| PN: | 140ARI03010 | REV.: | 01.00 |
| Origin Of Country: | France | Input Type: | Differential |
| MOQ: | 1 PCS | Deliver: | 3-5 Days |
| Highlight: | quantum unity processor,modicon quantum cpu |
||
Quick details:
Analog Input Module Modicon Quantum - 8 I Ni / Pt 100, 200, 500, 1000
Quantum | 140ARI03010 | Modicon | 140 ARI 030 10 | Analog RTD Input 8CH
The Modicon Quantum automation platform supports a full range of analog I/O modules designed to interface with a wide variety of fi eld devices. All modules meet internationally accepted IEC electrical standards that ensure reliability in harsh operating environments. For even better protection and extended life in extremely harsh environments, you can have your modules conformally coated. All Quantum I/O modules can be completely con fi gured using Unity Pro, Concept or ProWORX. The ability to specify an I/O address for each module in software makes it easy to add or change modules in your con fi guration without physically changing the application program
| Manufacturer: | Modicon Quantum |
| Series: | Analog Modules |
| Weight: | Ask |
| Analogue input number: | 8 |
| Input type: | Differential |
| Addressing requirement: | 9 input words |
| Analogue input type: | Temperature probe 2.5 mA Pt 100, Pt 200, Ni 100, Ni 200 |
| Temperature probe 0.5 mA Ni 100, Ni 200, Ni 500, Ni 1000 | |
| Temperature probe - 60...180 °C Ni 100, Ni 200, Ni 500, Ni 1000 | |
| Temperature probe - 200...850 °C Pt 100, Pt 200, Pt 500, Pt 1000 | |
| Temperature probe - 100...450 °C Pt 100, Pt 200, Pt 500, Pt 1000 | |
| Analogue input resolution: | 13 bits |
| Input impedance: | >= 10 MOhm |
| Absolute accuracy error: | 0.1 °C |
| Linearity error: | +/- 0.5 °C |
| +/- 0.01 % full scale | |
| Accuracy drift according to temperature: | +/- 0.9 °C at 0...60 °C |
| +/- 0.5 °C at 25 °C | |
| Isolation between channels and bus: | 1780 V AC 47...63 Hz for 60 s |
| 2500 V DC for 60 s | |
| Isolation between channels: | 300 Vrms AC |
| Update time: | 640 ms 2 wires/4 wires |
| 1200 ms 3 wires | |
| Fault type: | Overtacking scale |
| Broken wire | |
| Marking: | CE |
| Local signalling: | 8 LEDs red channel fault |
| 8 LEDs green channel is turned on | |
| 1 LED red external fault | |
| 1 LED green bus communication is present (Active) | |
| Bus current requirement: | 200 mA |
| Power dissipation in W: | 1 W |
| Module format: | Standard |
(1) 2 slots
(2) 3 slots
(3) 4 slots
(4) 6 slots
(5) 10 slots
(6) 16 slots
No. Each of these modules employ onboard firmware that will run a continuous self calibration routine.
No. There is no support for 120 ohm Nickel RTDs with the 140ARI03000 module.
The data counts are 0-32767 counts converting for which ever range is selected (0-766.66 Ohms or 0-4000 Ohms). I.E. If configuring the range for the channel to 0-766.66 Ohms then 766.66 Ohms = 32767 counts (approx. 42.7 counts per Ohm.)
