Honeywell Control Circuit Board 51403422-150 HDW Communication Controller

:Contorl Circuit Board HONEYWELL AMR BOARD 51403422-150 HDW COMMUNICATION CONTROLLER MEASUREX

Analog Input

Both the high and low level analog input processors perform signal conversion and conditioning functions:

• PV Source (Auto, Manual, Substituted)
• PV Clamping
• EU Conversion
• PV Value Status
• PV Alarming Bad PV PV Hi/Lo PV HiHi/LoLo PV Rate-of-Change +/-
• Software Calibration

They perform engineering unit conversion, including fifth-order polynomial temperature input characterization, with the high level processor receiving these inputs from mV/I converters.




QUICK DETAILS

1. Brand :Honwell
2. Model : 51403422-150
3. Place of Origin : USA


DESCRIPTION

• Contorl Circuit  Board
• MEASUREX
• COMMUNICATION CONTROLLER

Through use of a dual processor design and custom integrated circuits, the low level analog input processor supports software configuration per channel for different thermocouples or RTD types with excellent resolution and accuracy. Open thermocouple detection is performed once per scan so that no bad data is propagated for control processing.

The low level multiplexer processor provides an even more economical way to bring in a large number of data acquisition signals. Each processor can handle 32 points, using two 16- point FTAs. Each point is scanned once per second with a 1 second scan delay for processing. Open thermocouple detection is performed on a regular basis for all points. Options for either local or remote cold junction reference are available.

Smart Transmitter Multivariable Interface

The Smart Transmitter Multivariable (STI-MV) processor is the APM’s digital interface to Honeywell’s advanced series of smart transmitters.
