2711-B6C8L1 Allen Bradley Panelview Plus 1000 , Rev A Industrial Hmi Panels

HMI Touch Screen AB Allen Bradley PLUS 1000 2711-B6C8L1 PanelView Rev A FRN 4.44 24V




2711-B6C8L1 PARAMETER

The discontinued Allen Bradley Panelview 600 2711-B6C8L1 is an operator terminal that enables the user to interface with their machine.
This HMI has a 5 in. Color Display. This Panelview allows the user to connect using Panelbuilder 32 software and a DH+ and RS-232 Printer communication port with a 2711-NC14 communication cable(s).
The user is able to control the HMI using the Keypad/Touchscreen to input information and data. This unit is powered using 18-32 VDC power.
This unit has the following internal memory: 240 KB. If applicable this unit has an internal backlight replacement part number of 2711-NL5. The approximate shipping weight and dimensions are 6 lbs. and 14 x 11 x 8 in. The most common Series are: A, B, C, D, E, F, G, H, I, J, K, and L and the most common firmware include 1.00-4.48.
The Data Highway Plus terminals are capable of point-to-point communication with a single controller, as well as network communication with multiple controllers over an AB DH+ network. Direct access to controller data files minimizes ladder logic. Application files are easily downloaded or uploaded using PanelBuilder32 over the DH+ network, or directly via the on-board RS-232 printer port, or with a PC memory card. Application files are easily downloaded or uploaded using PanelBuilder32 over the DH + network or directly via the on-board RS-232 printer port. The PC memory card interface can also be used.


QUICK DETAILS

1. Brand :Allen Bradley (AB)
2. Model : 2711P-T10C4D8
3. Place of Origin : USA


DESCRIPTION

• Touch Display  Screen
• MONITOR
• PanelView



SPECIFITIONS
