3051S1CD4A2B12F1AD4K6M5Q4T1A1003 10.5 - 42.4 V-DC Pressure Temperature Transmitter

3051S1CD4A2B12F1AD4K6M5Q4T1A1003 10.5 - 42.4 V-DC Pressure Temperature Transmitter

3051S1CD4A2B12F1AD4K6M5Q4T1A1003 Description

3051S1CD4A2B12F1AD4K6M5Q4T1A1003 Key Features

• Ultra-High Precision: Up to 0.025% of span accuracy with 200:1 turndown ratio, ensuring reliable measurements across wide operating ranges.
• Long-Term Stability: 15-year stability guarantee and up to 15-year limited warranty, reducing maintenance costs and downtime.
• Coplanar Design: Patented Coplanar flange technology enables integrated manifold mounting, simplifying installation and reducing leak points.
• Advanced Diagnostics: Built-in loop integrity, process intelligence, and plugged impulse line detection for proactive maintenance and process optimization.
• Multi-Protocol Communication: Supports 4-20 mA HART, WirelessHART, and FOUNDATION Fieldbus for flexible integration with control systems.
• Robust Construction: All-welded hermetic design resists vibration, temperature extremes, and corrosive process fluids, ensuring reliable operation in demanding conditions.
• Safety Certified: SIL 2/3 certified to IEC 61508, meeting the highest safety standards for critical process applications.

3051S1CD4A2B12F1AD4K6M5Q4T1A1003 Materials & Applications

Materials

• Process Wetted Parts: 316L stainless steel, Alloy C-276, Alloy 400, Tantalum, gold-plated Alloy 400, or gold-plated 316L stainless steel (selectable based on process requirements).
• Housing: Cold-rolled steel with corrosion-resistant coating, providing mechanical protection and durability.
• Sensor Module: High-stability piezoresistive sensor with industrial-grade electronic components for long-term reliability.
• Sealing Components: PTFE, graphite-based gaskets, and high-performance elastomers for leak-proof operation.
• Electronics: Industrial-grade FR-4 printed circuit boards with conformal coating for enhanced EMI/ESD protection.

Typical Applications

• Oil & Gas Production: Wellhead monitoring, separator control, and pipeline pressure measurement.
• Refining & Petrochemicals: Distillation columns, reactors, and pipeline systems in corrosive environments.
• Power Generation: Boiler drum pressure, steam line monitoring, and feedwater systems.
• Chemical Processing: Reactors, mixers, and storage tanks with aggressive or corrosive fluids.
• Water & Wastewater: Treatment plants, pump stations, and reservoir level/pressure monitoring.
• Pharmaceutical & Food & Beverage: Sanitary process lines and clean-in-place (CIP) systems.

3051S1CD4A2B12F1AD4K6M5Q4T1A1003 Important Parameters
