Two specific drives are supported – the 1305 AC Drive and the 1336 Plus II drive. The drives are connected to a special Allen-Bradley ControlNet communication module (1203-CN1) to communicate with the drive interface library. A generic interface function block is provided for other drives that can connect to the scan port module 1203-CN1. The I/O data transfer of the generic drive has to be similar to the 1305 and 1336-PLUS-II drive
The function blocks provide access to all drive status and command information without the need for additional configuration. The information is available for the operator through a detail display and as parameters in the controller for control purposes. In addition to the standard status and command data, additional drive parameters can be accessed through four Datalinks, which have to be configured on the drive and in the function blocks.
Standard initialization processing is supported on the frequency output to the drive, making bumpless transition possible on communication recovery.
