Product Details:
Payment & Shipping Terms:
|
| Brand: | Schneider | Model: | 140NOC78100 |
|---|---|---|---|
| Palce Of Origin: | FR | Type: | Processor/Controller |
| Module Format: | Standard | Series: | Communications |
| Exchange Mode: | Full Duplex | Marking: | CE |
| High Light: | ethernet plc controllers,industrial automation using plc |
||
PLC Programmable Logic Controller SCHNEIDER 140NOC78100 COMMUNICATING MOUDLE
SIL
NOTE: For complete definitions and parameters related to SIL ratings refer tomIEC 61508, "Functional safety of electrical/electronic/programmable electronic safety related systems". Provided here is a partial definition. safety integrity level discrete level (1 out of a possible 4) for specifying the safety integrity requirements of the safety functions to be allocated to the E/E/PE safety-related systems, where safety integrity level 4 has the highest level of safety integrity and safety integrity level 1 has the lowest
(Definition IEC 61508) SIL2 project (application)
A project (application) that uses a Quantum Safety PLC (140 CPU 651 60S V1.00 or 140 CPU 671 60S V1.00) to implement Safety Functions in a Safety-Related System.
SIL3 project (application)
A project (application) that uses a Quantum Safety PLC (140 CPU 651 60S V2.00 or 140 CPU 671 60S V2.00) to implement Safety Functions in a Safety-Related
System.
SIR
Safety Integrity requirement
Safety Integrity requirements are derived from a risk assessment and describe the likelihood of a Safety Function to be performed satisfactorily, for instance the degree of certainty necessary for the Safety Function to be carried out.
sniffing reading the configuration out of a PLC
SRS
safety requirements specification
specification containing all the requirements of the safety functions that have to be performed by the safety-related systems
(Definition IEC 61508
| Manufacturer: | Modicon Quantum |
| Series: | Communications |
| Weight: | Ask |
| Product or component type: | Ethernet control module |
| Product compatibility: | 140CPU6xxxx |
| Communication port protocol: | Modbus TCP |
| Ethernet/IP | |
| Exchange mode: | Full duplex |
| Maximum number of connections: | 64 |
| Transmission rate: | 10/100 Mbit/s |
| Redundancy: | Yes hot standby redundant architecture |
| Topology: | Daisy chain loop |
| Redundant ring | |
| Web server: | Embedded |
| Communication service: | Embedded router |
| CIP implicit messaging (I/O communication) | |
| NTP time synchronization | |
| FDR server | |
| DHCP/BootP server | |
| SMTP e-mail notification | |
| Device Type Manager (DTM) | |
| SNMP agent | |
| Quality of Service (QoS) | |
| CIP Explicit messaging (client messaging) | |
| Embedded 4-port switch | |
| Ethernet service: | Rapid Scanning Tree Protocol (RSTP) |
| Transmission support medium: | Twisted pair |
| Port Ethernet: | 10BASE-T/100BASE-TX, connector type: RJ45 |
| Marking: | CE |
| Supply: | Via the power supply of the rack |
| Local signalling: | 1 LED green for communication on the bus (Active) |
| 1 LED green for configuration status (Ready) | |
| 1 LED green/red for device network status (Net Status 1) | |
| 1 LED green/red for extended DIO network status (Net Status 2) | |
| 1 LED green/red for module status (Mod Status) | |
| 1 LED green/red for network communication status (Net Status) | |
| Module format: | Standard |
