1C31223G01 Ovation Relay Panel Redundant Power Supply Module For Westinghouse

Westinghouse 1C31223G01 1776402-1  MODULE Redundant Power Supply Module

1C31223G01 Description

1C31223G01 Key Features

• 16-Channel Relay Outputs: Equipped with 16 independent single-pole double-throw (SPDT) relay outputs for versatile load control.
• High Switching Capacity: Supports a wide voltage range (24 VDC to 250 VAC) and high contact current rating for driving various industrial loads.
• Galvanic Isolation: Complete electrical isolation between input logic and output relays to protect the control system from field transients.
• LED Status Indicators: Individual LED lights for each channel to visually indicate power, communication status, and output activation.
• Wide Operating Temperature: Designed for extreme industrial environments, functioning reliably from -40°C to +70°C.
• Hot-Swappable Design: Supports module replacement under power without shutting down the entire system, minimizing downtime.
• Rugged Construction: Industrial-grade build with high resistance to shock, vibration, and electrical interference.
• Standard Rack Mounting: Compatible with standard system racks for easy installation and system integration.
• Comprehensive Protection: Built-in overcurrent, overvoltage, and short-circuit protection for safe and long-lasting operation.
• Industry Certifications: Complies with international safety standards including CE, UL, and RoHS.

1C31223G01 Material & Applications

Materials

• Housing: Flame-retardant, high-impact engineering plastic with excellent thermal stability and chemical resistance.
• Relay Contacts: Silver-cadmium oxide (AgCdO) alloy for high conductivity, low contact resistance, and long mechanical life.
• Circuit Board: High-temperature resistant glass-reinforced epoxy laminate (FR-4) with multi-layer copper traces.
• Terminals: Gold-plated or nickel-plated brass screw terminals for secure, corrosion-resistant connections.
• Internal Components: Industrial-grade relays, optocouplers, and passive components rated for extended lifespans.
• Structural Parts: Steel mounting brackets and aluminum heat sinks for structural rigidity and effective heat dissipation.

Applications

• Power Generation: Control of auxiliary systems, switchgear, and safety interlocks in thermal, nuclear, and hydroelectric plants.
• Oil & Gas Industry: Actuation of valves, pumps, and emergency shutdown (ESD) systems in refineries and pipelines.
• Chemical Processing: Safe control of reactors, mixers, and material handling systems.
• Water & Wastewater Treatment: Control of filter valves, pumps, and chemical dosing equipment.
• Manufacturing Automation: On/off control of conveyors, motors, and pneumatic/hydraulic actuators.
• Metallurgical Industry: Control of furnace mechanisms, material feeders, and cooling systems.
• Marine & Offshore: Automation of deck machinery, ballast systems, and engine control.
• Building Automation: Control of HVAC systems, lighting, and fire safety equipment.

1C31223G01 Important Parameters
