Carbon Steel / Stainless / Alloy Fisher 8580 Butterfly Valve Fugitive Emission NACE ATEX CUTR

: Large Image : Carbon Steel / Stainless / Alloy Fisher 8580 Butterfly Valve Fugitive Emission NACE ATEX CUTR

Product Details:

Place of Origin:	America
Brand Name:	Fisher
Certification:	dose not supply
Model Number:	8580

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	negotiable
Packaging Details:	New in original box
Delivery Time:	5-8 work days
Payment Terms:	T/T
Supply Ability:	100

Contact Now

Detailed Product Description

Brand:	Fisher	Model:	8580
Origion:	America	Flow Characteristics:	Linear
Critical Service:	General Service	Seat / Seal Type:	Metal, Soft
Highlight:	differential pressure flow transmitter , high temperature differential pressure transmitter

Carbon Steel, Stainless, Alloy Fisher™ 8580 High Performance Butterfly Valve Fugitive Emission, NACE, ATEX, CUTR

The Fisher 8580 high performance Butterfly valve provides the capability for enhanced shutoff and features an eccentrically-mounted disk with either a soft or metal seal. Experience excellent throttling and on/off performance with this control valve.

Specifications

Certifications	SIL capable, PED, CRN, Fugitive Emission, NACE, ATEX, CUTR
Critical Service	General Service
Flow Characteristics	Linear
Material	Carbon Steel, Stainless, Alloy
Operating Temperature	Standard Temperature, High Temperature
Power Source	Electric, Hydraulic, Pneumatic, Lever, Gear, Electro-Hydraulic
Pressure Class	PN, ASME
Process Connection Type	Flanged, Single Flanged, Double Flanged, Lugged, Wafer
Seat / Seal Type	Metal, Soft
Shutoff Class	MSS SP-61, Class IV (FCI 70-2), Class VI (FCI 70-2)
Standards	B16.34
Stem	Live Loaded, Adjustable Packing
Valve Size	NPS 2, NPS 3, NPS 4, NPS 6, NPS 8, NPS 10, NPS 12
Valve Size Standard	NPS, DN
Other Configurations	Contact your local Emerson business partner or sales office to learn about additional specifications or options for this product.

Features

The actuator/valve assembly action can be converted from push-down-to-open to push-down-to-close, or vice versa, without additional parts.
Both the metal and soft seal rings have pressure-assisting sealing action that ensures tight shutoff regardless of pressure drop.
Standard valve construction includes conductive packing to provide electrical bonding for hazardous area applications.
The valve will operate at elevated temperatures, with the appropriate trim components.
Additional travel indication can be achieved by using the indication line on the shaft, along with the disk position markings on the packing follower.
Redundant shaft retention provides added protection. The packing follower, anti-blowout ring, and shaft groove interact to hold the shaft securely in the valve body.

Fisher 8580 Control Valve with FieldQ™ Actuator

* Testing Minimum: 1,000,000 Cycles

* Valve Body Size Range: NPS 2, 3, 4, 6, 8, 10, and 12 DN 50, 80, 100, 150, 200, 250, and 300

* Pressure Rating: CL150, 300 per ASME B16.34

* Explosion-proof applications with integral 4-20mA position feedback: TopWorx™ DXP valve controller

* Explosion-proof, intrinsically safe, non-incendive applications with integral 4–20 mA position feedback: FIELDVUE DVC6200 instrument

* Intrinsically safe, non-incendive applications with integral 4–20 mA position feedback: FIELDVUE DVC2000 instrument
