AI830A 3BSE040662R1 Analog Input Module - RTD Digital I O Module ABB

The AI830A, with the article number 3BSE040662R1, is a high-performance Analog Input Module manufactured by ABB for its acclaimed ABB Ability™ System 800xA and Symphony Harmony series control systems. This module is designed to interface with the real world by converting analog signals from field instruments (such as temperature sensors, pressure transmitters, and flow meters) into precise digital values for the control system to process. It is a critical component for accurate data acquisition in demanding industrial automation, process control, and supervisory applications. The module is known for its reliability, high accuracy, and robust design, making it suitable for harsh industrial environments.

3BSE040662R1 Features

• •
  ​​High Channel Density:​​ Provides 8 single-ended or 4 differential analog input channels in a single module slot, optimizing control cabinet space.
• •
  ​​Wide Signal Range Support:​​ Configurable for various input types including voltage (e.g., ±10V, 0-10V) and current (e.g., 0-20mA, 4-20mA), offering great flexibility.
• •
  ​​High Accuracy and Resolution:​​ Features high-resolution analog-to-digital conversion, ensuring precise measurement of process variables for improved control quality.
• •
  ​​Advanced Diagnostics:​​ Includes comprehensive diagnostic capabilities such as channel failure detection, wire break detection (for 4-20mA signals), and over-range/under-range alarms, enhancing system maintenance and availability.
• •
  ​​Hot-Swappable:​​ Supports hot-swapping, allowing for module replacement or maintenance without shutting down the entire control system, which minimizes downtime.
• •
  ​​Robust Electrical Isolation:​​ Features high-grade channel-to-channel and channel-to-system isolation, protecting the system from ground loops and electrical noise in harsh industrial environments.
• •

  ​​SIL Certification:​​ The module is often developed and certified for use in Safety Instrumented Systems (SIS) up to a specific Safety Integrity Level (SIL), as per relevant standards.



  3BSE040662R1 Material & Applications

  •

  ​​Material:​​ The module is constructed with a robust metal housing and utilizes industrial-grade electronic components on a printed circuit board (PCB). It is designed to withstand typical industrial conditions, including temperature variations, humidity, and vibration.

  •

  ​​Applications:​​ The AI830A is primarily used in industrial automation and process control systems across various sectors.

  • •
    ​​Process Industries:​​ Chemical, Oil & Gas, Refining, Pharmaceutical, and Power Generation for monitoring pressure, temperature, flow, and level.
  • •
    ​​Manufacturing:​​ For data acquisition from sensors and transmitters on production lines.
  • •

    ​​Water and Wastewater Treatment:​​ Monitoring process variables like pH, turbidity, and tank levels.
