MR-J2S-70B-PY096 Mitsubishi DRIVE AC Servo Amplifier J2-Super Series 220(V)10(KHz)
MR-J2S-70B-PY096 Description
The Mitsubishi MR‑J2S‑70B‑PY096 is a high‑performance 0.75kW (750W) AC servo amplifier from the MELSERVO‑J2‑Super Series, featuring SSCNET III/H fiber‑optic communication and a PY096 special specification for enhanced industrial compatibility. It is a single‑axis servo drive designed for precise motion control, supporting position, speed, and torque control modes. The unit operates on 200–230 VAC (single‑phase 230V / three‑phase 200–230V, 50/60Hz) and integrates advanced control algorithms for high‑speed, high‑precision automation. The PY096 suffix denotes a custom‑configured variant optimized for specific industrial machinery, ensuring seamless integration with Mitsubishi servo motors (e.g., HC‑SFS, HC‑LFS series) and factory automation systems.
MR-J2S-70B-PY096 Key Features
- SSCNET III/H High‑Speed Communication: Fiber‑optic serial communication for fully synchronized motion control, enabling high‑speed data exchange with controllers and minimal latency.
- 0.75kW Rated Output: Delivers stable power for medium‑duty industrial motion applications with high torque density.
- Multi‑Mode Control: Supports position, speed, and torque control modes for flexible adaptation to diverse automation tasks.
- Built‑in Dynamic Brake: Integrated dynamic braking for rapid deceleration and safe stopping, enhancing operational safety.
- High‑Frequency Response: Speed loop frequency response of ≥550 Hz for ultra‑fast positioning and high‑frequency operation.
- Adaptive Vibration Suppression: Automatically detects mechanical resonance and adjusts filter parameters to dampen vibrations, ensuring smooth operation.
- Advanced Auto‑Tuning: Model‑adaptive control and real‑time auto‑tuning simplify setup and optimize performance for various mechanical systems.
- Comprehensive Protection: Overcurrent, overvoltage, overload, encoder fault, undervoltage, and overspeed protection for reliable operation.
- Natural Cooling: Self‑cooling design eliminates the need for fans, reducing maintenance and improving reliability.
- PY096 Special Specification: Custom‑engineered variant for enhanced compatibility and performance in targeted industrial environments.
- User‑Friendly Interface: 5‑digit LED display and keypad for parameter setup, status monitoring, and fault diagnosis.
MR-J2S-70B-PY096 Materials & Applications
Materials
- Housing: Rugged industrial‑grade metal alloy with corrosion‑resistant coating, providing durability and effective heat dissipation.
- Internal Components: High‑reliability industrial‑grade semiconductors, high‑precision current sensors, and isolated communication modules for stable performance.
- Connectors: Gold‑plated terminals for low contact resistance, ensuring reliable signal and power transmission.
- Circuit Board: High‑temperature‑resistant PCB with conformal coating for protection against dust and moisture.
MR-J2S-70B-PY096 Typical Applications
- Machine Tools: CNC milling machines, lathes, and grinding machines requiring high‑precision positioning.
- Packaging Machinery: High‑speed filling, sealing, and labeling equipment.
- Robotics: Articulated robots, SCARA robots, and Cartesian coordinate robots.
- Semiconductor Manufacturing: Wafer handling, precision positioning, and assembly equipment.
- Printing & Textile Machinery: High‑speed printing presses, winding machines, and tension control systems.
- Material Handling: Automated conveyors, pick‑and‑place systems, and linear actuators.
- Food Processing: Precision cutting, sorting, and packaging machinery.
MR-J2S-70B-PY096 Important Parameters
| Parameter |
Specification |
| Part Number |
MR‑J2S‑70B‑PY096 |
| Product Series |
Mitsubishi MELSERVO‑J2‑Super Series |
| Product Type |
Single‑Axis AC Servo Amplifier |
| Rated Output Power |
0.75 kW (750 W) |
| Power Supply |
Single‑phase AC 230 V; Three‑phase AC 200–230 V, 50/60 Hz |
| Communication Interface |
SSCNET III/H Fiber‑Optic |
| Control Modes |
Position, Speed, Torque |
| Speed Loop Frequency Response |
≥ 550 Hz |
| Built‑in Brake |
Dynamic Brake |
| Cooling Method |
Natural (Self‑Cooling) |
| Digital Inputs |
1 x 24 VDC (Sink/Source) |
| Digital Outputs |
1 x Relay Output |
| Analog Outputs |
2 x ±10 VDC |
| Protection Functions |
Overcurrent, Overvoltage, Overload, Encoder Fault, Undervoltage, Overspeed |
| Operating Temperature |
0°C to +55°C (Non‑Condensing) |
| Storage Temperature |
-20°C to +65°C |
| Ambient Humidity |
5% to 90% RH (Non‑Condensing) |
| Weight |
Approx. 1.7 kg |
| Compatible Motors |
Mitsubishi HC‑SFS, HC‑LFS, HC‑RFS, HC‑UFS Series |
| Special Specification |
PY096 (Custom Industrial Configuration) |
