MR-J2S-40CP-S186 AC Servo Amplifier Industrial Servo MELSERVO Instruction Manual

• High-Speed Serial Network (SSCNET):​ Enables high-speed, synchronous communication between the drive and a motion controller (e.g., Mitsubishi Q series PLC), simplifying wiring, reducing noise interference, and facilitating advanced multi-axis coordination.
• Real-Time Auto-Tuning:​ Automatically and continuously adjusts servo gains (position loop, speed loop) based on the load inertia, optimizing response and stability without manual intervention for various machine conditions.
• Advanced Vibration Suppression Control:​ Features adaptive filters and a vibration suppression algorithm to detect and dampen mechanical resonance, minimizing settling time and improving machining or positioning finish.
• High-Resolution Encoder:​ The integrated system comes with a high-pulse encoder (standard 131,072 pulses/rev, with S186 specification offering 1,048,576 pulses/rev for extreme precision), providing fine position feedback for ultra-accurate control.
• Robust Design & Protection:​ Built with a durable metal heat sink, features comprehensive protective functions against overload, overvoltage, overcurrent, and overheating, ensuring stable operation in industrial environments.
• Versatile Control Modes:​ Supports torque, speed, and position control modes, making it adaptable to a wide range of application requirements.

• Materials:
  • Drive Housing & Heat Sink:​ Aluminum alloy for effective heat dissipation.
  • Circuit Boards:​ Fiberglass (FR-4) with conformal coating for moisture and dust protection.
  • Internal Components:​ Industrial-grade capacitors, power transistors, and connectors.
  • Motor Frame:​ Aluminum die-casting.
  • Motor Shaft:​ High-strength steel.
  • Motor Stator/Rotor:​ Silicon steel laminations and high-grade permanent magnets.
• Applications:
  • CNC machine tools (lathes, milling machines)
  • Industrial robots and automated assembly lines
  • Semiconductor manufacturing equipment
  • Packaging and printing machinery
  • Material handling and transfer systems
  • Precision test and measurement equipment
