QJ72LP25GE Mitsubishi Universal Model Redundant Power Supply Module 5 V DC/3 A

QJ72LP25GE Description

The QJ72LP25GE is a high‑speed optical loop network module designed for remote I/O communication in industrial control systems. Operating as a remote station in a duplex fiber‑optic ring, it enables reliable, noise‑immune data exchange between controllers and distributed I/O devices at 10 Mbps transmission speed. Using GI‑62.5/125 multimode fiber, it supports network distances up to 30 km and up to 65 stations (1 master + 64 remote I/O stations), making it ideal for large‑scale, EMI‑prone industrial environments.



QJ72LP25GE Key Features

• Duplex Optical Loop Topology: Dual‑ring redundancy ensures uninterrupted communication if a cable fault occurs.
• High Noise Immunity: Fiber‑optic transmission eliminates EMI/RFI interference for stable operation in harsh electrical environments.
• Large Network Capacity: Supports up to 65 stations and 16,384 link points (LB/LW) for extensive I/O control.
• Long‑Distance Communication: Maximum 30 km total network length; up to 2 km between individual stations.
• High‑Speed Data Transfer: 10 Mbps baud rate for fast, real‑time data exchange.
• RAS Diagnostic Functions: Built‑in loopback, cable break detection, and line monitoring for easy maintenance.
• Compact Form Factor: Single‑slot installation with low power consumption for space‑saving integration.
• Multi‑Protocol Compatibility: Supports MELSECNET/H and MELSECNET/10 modes for flexible system integration.

QJ72LP25GE Materials & Applications

Materials

• Housing: Flame‑retardant, impact‑resistant thermoplastic alloy (UL94 V‑0 rated) for electrical insulation and mechanical protection.
• PCB: High‑temperature glass‑epoxy laminate with gold‑plated contacts for signal integrity and corrosion resistance.
• Optical Connectors: Nickel‑plated ceramic ferrules for low‑loss, vibration‑resistant fiber connections.
• Internal Components: Conformal‑coated electronic parts for moisture, dust, and chemical resistance.

Typical Applications

• Process Industries: Chemical, oil/gas, and water treatment plants with high electrical noise and long‑distance I/O.
• Manufacturing: Automotive assembly lines, semiconductor fabs, and packaging machinery requiring distributed control.
• Power Generation: Thermal, hydro, and renewable power plants with remote monitoring and control systems.
• Infrastructure: Building automation, airport systems, and railway signaling with EMI‑sensitive equipment.
• Large‑Scale Factories: Centralized control with remote I/O expansion across wide industrial sites.

QJ72LP25GE Important Parameters
