AJ65SBTB1-8TE Mitsubishi Universal Model Redundant Power Supply Module 5 V DC/3 A

AJ65SBTB1-8TE Description

AJ65SBTB1-8TE Key Features

• 8-Channel High-Speed Output: 8 independent PNP (source-type) transistor output channels for precise load control.
• Fast Response Time: Rapid switching with OFF→ON response ≤0.5ms and ON→OFF response ≤1.5ms (resistive load).
• Screw Terminal Connection: Industrial-grade screw terminals for secure, easy field wiring and maintenance.
• Full Electrical Isolation: Optocoupler isolation between I/O circuits and CC-Link network for noise immunity.
• Wide Voltage Compatibility: Operates at 12–24V DC load voltage (10.2–26.4V DC operating range).
• Single Station Occupancy: Compact form factor occupies only 1 CC-Link station, maximizing space efficiency.
• Integrated Protection Circuits: Built-in overload and overheat protection for module and connected load safety.
• Surge Suppression: Internal Zener diodes for surge voltage protection on output channels.
• LED Status Indicators: Front-panel LEDs for power, network communication, and individual output status.
• Robust Industrial Construction: Durable housing resistant to vibration, shock, and temperature fluctuations.
• Global Certifications: Compliant with UL, cUL, CE (EMC), and RoHS standards for worldwide deployment.
• DIN-Rail Mountable: Standard DIN-rail installation for flexible system configuration and expansion.
• Low Power Consumption: Energy-efficient design minimizing power requirements in control cabinets.

AJ65SBTB1-8TE Materials & Applications

Materials

• Housing: High-strength, flame-retardant thermoplastic (ABS/PC blend) for insulation and physical protection.
• Terminals: Nickel-plated brass screw terminals with corrosion resistance for reliable electrical connections.
• Circuit Board: High-temperature FR-4 glass epoxy PCB with surface-mount technology for stable performance.
• Internal Components: Industrial-grade switching transistors, optocouplers for isolation, and precision protection circuits.
• Indicators: Long-life LED indicators for power (PWR), network (NET), and output channel status (OUT1–OUT8).

Typical Applications

• Factory Automation: Control of solenoid valves, pneumatic/hydraulic actuators, relays, and indicator lamps.
• Small Assembly Machines: Pick-and-place units, clamping mechanisms, and positioning actuators.
• Packaging Equipment: Small sealing devices, labeling heads, and conveyor diverters.
• Material Handling: Miniature conveyors, sorting mechanisms, and motor control relays.
• Machine Tools: Coolant system valves, pneumatic clamps, and safety interlock controls.
• Semiconductor Equipment: Precision actuators, sensor controls, and small pneumatic systems.
• Food & Beverage: Small filling valves, dosing mechanisms, and packaging line actuators.
• Pharmaceutical: Laboratory automation, small assembly units, and precision control devices.

AJ65SBTB1-8TE Important Parameters
