AJ65BTB1-16T Mitsubishi Redundant Power Supply Module 12/24VDC (0.5A) 8 K Steps

AJ65BTB1-16T Description

AJ65BTB1-16T Key Features

• 16 Sink‑Type Transistor Outputs: 8 points per common group, 0.5 A per point, 4 A per common for flexible load control.
• Wide Voltage Compatibility: 12 V DC to 24 V DC (±10%) for broad field device support.
• Fast Response Time: 2 ms maximum (resistive load) for high‑speed switching applications.
• Photocoupler Isolation: Electrical isolation between network and output circuits enhances noise immunity and safety.
• Integrated Protection: Overload, short‑circuit, and surge protection (Zener diode) safeguards module and field devices.
• 2‑Piece Terminal Block: 1‑wire, M3 screw terminals for secure, tool‑friendly wiring and maintenance.
• LED Status Indicators: Power, network link, and individual output status LEDs for real‑time diagnostics.
• DIN‑Rail Mount: Compact, standard form factor for easy installation in control cabinets.
• Single Station Occupancy: Consumes 1 CC‑Link station for efficient network resource usage.

AJ65BTB1-16T Materials & Applications

Materials

• Housing: Flame‑retardant ABS/PC blend, industrial impact resistance and electrical insulation.
• PCB: Glass‑epoxy laminate with gold‑plated contacts for reliable signal transmission.
• Terminals: Nickel‑plated M3 screw terminals (2‑piece, removable) for corrosion resistance.
• Isolation Components: High‑speed photocouplers for electrical isolation between network and outputs.
• Protection Circuitry: Surge suppressors, Zener diodes, and overcurrent sensors for harsh industrial environments.

Typical Applications

• Manufacturing Automation: Control of solenoid valves, contactors, and indicator lights on assembly lines.
• Packaging Machinery: Driving actuators and sensors for labeling, sealing, and sorting equipment.
• Process Control: On/off control of pumps, fans, and valves in water treatment and food processing plants.
• Building Automation: Control of lighting, HVAC dampers, and security system relays.
• Distributed I/O Systems: Remote output expansion for large‑scale factory automation via CC‑Link networks.

AJ65BTB1-16T Important Parameters
