AJ65BT-D62D Mitsubishi Universal Model Redundant Power Supply Module 12/24VDC 0.5A

Name: AJ65BT-D62D Mitsubishi Universal Model Redundant Power Supply Module 12/24VDC 0.5A
Brand: Shenzhen Wisdomlong Technology CO.,LTD
SKU: AJ65BT-D62D
Price: 10000.00 USD
Availability: InStock

Product Details:

Place of Origin:	Japan
Brand Name:	MITSUBISHI
Certification:	CE
Model Number:	AJ65BT-D62D

Detail Information

Place of Origin:

Japan

Brand Name:

MITSUBISHI

Certification:

Model Number:

AJ65BT-D62D

Brand:

MITSUBISHI

Modenl Number:

AJ65BT-D62D

Country Of Origin:

Japan

Program Capacity:

8 K Steps

Basic Operation Processing Speed (LD Instruction):

0.12 μs

Input:

24VDC

Output:

12/24VDC (0.5A).

Type:

Redundant Power Supply Module

Highlight:

High Light

Highlight:

analog interface module

diode redundancy module

Trading Information

Minimum Order Quantity:

Price:

Contact

Packaging Details:

new and original

Delivery Time:

5-7 days

Payment Terms:

T/T, Western Union,paypal

Supply Ability:

100

Product Description

Mitsubishi Universal model AJ65BT-D62D Redundant Power Supply Module

AJ65BT-D62D Description

The AJ65BT-D62D is a high-speed, bipolar 2-channel analog voltage output module designed for Mitsubishi's MELSEC AnS series PLCs. It is part of the CC-Link network family, functioning as a remote device station. This module receives digital output data from the PLC master station via the high-speed CC-Link field network and converts it into precise analog voltage signals (-10V to +10V). It is essential for controlling devices like variable frequency drives (VFDs), servo amplifiers, and other actuators that require analog voltage command signals in a distributed, network-based control architecture.

AJ65BT-D62D Features

CC-Link Network Integration: Operates as a remote device station on the CC-Link network, enabling centralized control and data exchange with the PLC master over a single bus, reducing wiring complexity.
High-Speed, High-Resolution Output: Offers 12-bit resolution for fine analog control. A digital value of -2000 to +2000 corresponds linearly to the analog output range of -10V to +10V.
Bipolar Voltage Output: Each of the two channels can independently output both positive and negative DC voltage, suitable for applications requiring bidirectional control commands.
Output Hold/Clear Function: The output mode upon communication error (e.g., CPU stop, cable disconnection) can be set to either hold the last output value or clear to a preset safe state (0V or other), enhancing system safety.
Easy Scaling: Allows for user-defined scaling between the digital values from the PLC and the output voltage, providing application flexibility.

AJ65BT-D62D Material & Primary Applications

Material: The module casing is made of robust, flame-retardant plastic (ABS/Polycarbonate). The terminal block is a high-grade screw-clamp type for secure connections. Internal components include a precision digital-to-analog converter (DAC) and signal conditioning circuitry on a glass epoxy PCB.
Primary Applications: Used in networked control systems for precise analog voltage command.
- Speed and torque control of variable frequency drives (VFDs) for motors.
- Command input for servo amplifiers and motion controllers.
- Setting points for process controllers or analog recorders.
- Any application requiring a distributed, network-based analog voltage output.

AJ65BT-D62D Key Specifications

Parameter	Specification
Model	AJ65BT-D62D
Module Type	CC-Link Remote Device Station, Analog Output Module
Number of Channels	2 channels
Output Signal Range	DC -10 V to +10 V
Permissible Load Impedance	2 kΩ or higher
Digital Input	12-bit signed binary (-2000 to +2000)
Resolution	1/4000 (10 mV)
Overall Accuracy	±0.5% of full scale (±100 mV)
Conversion Speed	2 ms/channel (4 ms for 2 channels)
Output Characteristics	Bipolar, Linear
Output Hold/Clear	Configurable on communication error (Hold/Clear to 0V)
Insulation	Photocoupler insulation between internal circuits and analog output circuits. No insulation between analog output channels.
Occupied Stations (CC-Link)	1 station (32 points I/O)
Internal Current Consumption (5VDC)	90 mA (from external 5V power via extension cable, not from PLC base)
External Supply Voltage	DC 24 V +20%/-15% (for module operation)
Dimensions (W x H x D)	55 mm x 90 mm x 80.5 mm
Weight	Approx. 0.2 kg
