AJ65BTC1-32T Mitsubishi Universal Redundant Power Supply Module 12/24VDC (0.5A)

AJ65BTC1-32T Description

AJ65BTC1-32T Key Features

• 32-Channel High-Density Output: Equipped with 32 independent sink-type (NPN) transistor output channels for extensive load control capacity.
• High-Speed Response: Fast output switching with a response time of ≤2ms, supporting high-speed automation sequences.
• 40-Pin FCN Connector: Utilizes a 40-pin one-wire FCN connector (A6CON1 compatible) for organized, high-density field wiring.
• Full Galvanic Isolation: Electrical isolation between I/O circuits and the CC-Link network to suppress electrical noise and interference.
• Wide Voltage Compatibility: Operates on a 12–24V DC load voltage, compatible with standard industrial components.
• Single Station Occupancy: Compact design occupies only 1 CC-Link station, maximizing network and cabinet space efficiency.
• LED Status Indicators: Front-panel LEDs for power, network communication, and output channel status for quick diagnostics.
• Robust Industrial Build: Durable construction resistant to vibration, shock, and temperature variations for continuous operation.
• Overcurrent Protection: Built-in overcurrent and reverse polarity protection to safeguard module and connected loads.
• Global Certifications: Compliant with UL, cUL, CE (EMC), and RoHS standards for worldwide industrial application.
• DIN-Rail Mountable: Standard DIN-rail installation for easy mounting and system expansion.
• Low Power Consumption: Energy-efficient design minimizing the overall power draw of the control system.

AJ65BTC1-32T Materials & Applications

Materials

• Housing: High-strength, flame-retardant thermoplastic (ABS/PC blend) providing electrical insulation and physical protection.
• Connectors: Industrial-grade 40-pin FCN connector with corrosion-resistant, gold-plated contacts for reliable signal transfer.
• Circuit Board: High-quality FR-4 glass epoxy PCB with surface-mount components for stable performance and longevity.
• Internal Electronics: Precision switching transistors, optocouplers for isolation, and voltage regulation circuits.
• Indicators: Long-life LED indicators for power (PWR), network (NET), and individual output status (OUT1–OUT32).

Typical Applications

• Factory Automation: Control of solenoid valves, pneumatic/hydraulic actuators, relays, and indicator lamps.
• Assembly Lines: Multi-station pick-and-place machines, clamping units, and positioning mechanisms.
• Packaging Machinery: Form-fill-seal equipment, labeling heads, and sealing mechanisms.
• Material Handling: Conveyor systems, diverters, sorters, and motor contactors.
• Machine Tools: Control of coolant systems, pneumatic clamps, and safety interlocks.
• Textile & Printing: Yarn control, feed rollers, and sheet registration systems.
• Food & Beverage: Filling lines, capping machines, and conveyor control.
• Pharmaceutical: Blister packaging, tablet counting, and laboratory automation.

AJ65BTC1-32T Important Parameters
