AJ65SBTC1-32DT1 Redundant Power Supply Module Mitsubishi Universal Model 0.12 μS

AJ65SBTC1-32DT1 Description

AJ65SBTC1-32DT1 Key Features

• 32-Point Mixed I/O: 16-channel DC24V digital input + 16-channel sink-type transistor output (32 total points), high-density design to minimize module count and control cabinet space.
• CC-Link Compliance: Fully supports CC-Link Ver.1.10/2.00, with auto-selectable baud rates up to 10 Mbps for fast, stable data transmission between field and main PLC.
• Ultra-Slim Compact Form Factor: Slim profile optimized for dense DIN-rail mounting, maximizing cabinet space utilization.
• Photocoupler Isolation: 500V AC isolation between input/output/internal circuits, delivering strong anti-electromagnetic interference (EMI) and noise immunity for reliable operation in industrial environments.
• Flexible Response Settings: Configurable input response time (0.2/1.5/5/10 ms) to match different application speed requirements; fast output switching for real-time control.
• Clear LED Diagnostics: Individual channel input/output status LEDs + module/network status indicators for quick fault location and maintenance.
• Easy Installation: DIN-rail (TH35-7.5) mountable with screw-clamp terminals, plug-and-play setup, automatic network recognition, and simple DIP-switch configuration.
• High Reliability: Industrial-grade construction with vibration/shock resistance, wide temperature tolerance, and low power consumption for long-term stable operation.
• Single Station Occupancy: Occupies only 1 CC-Link remote device station, simplifying network addressing and resource management.

AJ65SBTC1-32DT1 Materials & Applications

Materials

• Housing: High-strength, flame-retardant engineering thermoplastic (UL94 V-0 rating), impact-resistant and fire-safe for industrial use.
• Terminals: Nickel-plated brass screw terminals (M3 size), corrosion-resistant, secure wire connection (torque: 0.59–0.88 N·m), supports 0.3–2.0 mm² stranded wires.
• Internal Circuitry: FR-4 glass epoxy PCB with high-reliability optocouplers, transistors, and surface-mount components for stable signal isolation and switching.
• Mounting: Reinforced plastic DIN-rail clip (6-direction mounting) + M4 screw holes for fixed installation (torque: 0.78–1.08 N·m).
• Output Components: High-performance power transistors with overcurrent protection, ensuring long service life for actuator control.

Typical Applications

• Factory Automation: Assembly lines, packaging machines, conveyor systems, sorting equipment for sensor input and solenoid/valve control.
• Machine Tools & Robotics: CNC machines, machining centers, robotic arms for limit switch input and pneumatic/hydraulic actuator output control.
• Material Handling: Warehouse logistics, lifting equipment, palletizers for position detection and motion control.
• Process Control: Food & beverage, pharmaceutical, chemical plants requiring stable mixed I/O in EMI-heavy environments.
• General Industrial Equipment: Textile, plastic, metal processing machinery for distributed digital signal acquisition and on/off control.

AJ65SBTC1-32DT1 Important Parameters
