AJ35TB2-16D Redundant Power Supply Module Mitsubishi Universal Model 5 V DC/3 A

AJ35TB2-16D Description

AJ35TB2-16D Key Features

• 16-channel Integrated DC Input: 16 independent digital input points to meet large-scale on-site signal collection requirements.
• Wide Compatibility: Supports both sink and source type sensor input, adapting to most 24V DC industrial field devices.
• Selectable Input Response Speed: Matches different signal filtering demands to avoid interference pulse misjudgment.
• Optocoupler Galvanic Isolation: Completely isolates external field circuits and internal control circuits to suppress electromagnetic interference.
• Fieldbus Network Adaptation: Connects to standard industrial fieldbus, occupies only one station address to save network resources.
• LED Status Indication: Onboard LEDs for power, network communication and each input channel status for quick on-site inspection and maintenance.
• Screw Terminal Wiring: Reliable screw terminal connection, anti-loosening and suitable for high-vibration industrial environments.
• DIN Rail Mounting: Standard DIN rail installation, easy assembly, replacement and system expansion.
• Compact Slim Structure: Small footprint saves cabinet space, ideal for compact control panel layout.
• Industrial Environmental Adaptability: Resists temperature change, humidity and mechanical vibration for stable operation in harsh workshops.

AJ35TB2-16D Materials & Applications

Materials

• Housing: High-strength flame-retardant engineering plastic with UL94 V-0 rating, excellent insulation, impact resistance and aging resistance.
• Circuit Board: High-quality FR-4 glass epoxy multilayer PCB, using industrial SMT components with stable heat dissipation and signal transmission.
• Terminals: Nickel-plated brass screw terminals, corrosion resistant, low contact resistance and reliable long-term wiring.
• Internal Components: Industrial-grade optocouplers, filter capacitors, voltage regulation chips and surge suppression components.
• Indicators: High-brightness long-life LED lamps for clear status display in various lighting conditions.

Typical Applications

• Factory Automation: Signal acquisition of limit switches, proximity sensors and emergency stop buttons on assembly lines.
• Packaging Machinery: Photoelectric detection, position sensing and workflow signal collection.
• Machine Tools: Stroke limit, safety interlock and operation panel switch signal input.
• Material Handling: Conveyor detection sensors, sorting position and flow monitoring signal collection.
• Food & Beverage Machinery: Raw material detection, container position and equipment status signal acquisition.
• Textile & Printing Equipment: Running state detection and position sensor signal input.
• General Industrial Control: Distributed remote I/O expansion and on-site switching signal centralized collection.

AJ35TB2-16D Important Parameters
