| Brand: | GE | Model: | IC200MDL740 |
|---|---|---|---|
| Origin: | USA | Warranty: | 1 Year |
| Highlight: | ac servo motor,electric servo motor |
||
24 VDC Positive Logic, 0 .5A per point, 16 points IC200MDL740 GE VersaMax Discrete Output Module
| IC200MDL730 | IC200MDL740 | IC200MDL741 | |
| Product Name | VersaMax Discrete Output Module, 24 VDC Positive Logic 2 .0A per point w/ESCP, 8 points |
VersaMax Discrete Output Module, 24 VDC Positive Logic, 0 .5A per point, 16 points |
VersaMax Discrete Output Module, 24 VDC Positive Logic, 0 .5A per point w/ESCP, 16 points |
| Lifecycle Status | Active | Active | Active |
| Output Voltage | 17 .5-30 VDC, 24 VDC nominal | 10 .2-30 VDC, 12/24 VDC nominal | 18-30 VDC, 24 VDC nominal |
| Number of Points | 8 | 16 | 16 |
| Channel to Channel Isolation | No | No | No |
| Load Current per Point | 2 .0 A per point | 0 .5 A per point | 0 .5 A per point |
| Input and Output Response Time- On/Off (ms) |
0 .5 | 0 .2/1 .0 | 0 .5/0 .5 |
| Protection | Short circuit protection, overcurrent protection (each output) |
No internal fuses (each output) | Short circuit protection, overcurrent protection, free-wheeling diodes (each output) |
| Points per Common | 1 group of 8 | 1 group of 16 | 1 group of 16 |
| External Power Supply | 18-30 VDC, 24 VDC nominal | 10 .2-30 VDC, 12/24 VDC nominal | 18-30 VDC, 24 VDC nominal |
| Load Current | 2 .0 A at 30 VDC maximum (resistive) per point, 8 .0 A max . per module |
0 .5 A at 30 VDC maximum (resistive); 2 .0 A inrush maximum for 100 ms |
0 .5 A at 30 VDC maximum (resistive); 2 .0 A inrush maximum for 100 ms |
| 5V Backplane Current Consumption (mA) |
50 maximum | 45 maximum | 75 maximum |
| LED Indicators | One LED per point shows individual point ON/OFF state (logic side) . FLD PWR LED indicates field power is present . OK LED indicates backplane power is present . |
One LED per point shows individual point ON/OFF state (logic side) . FLD PWR LED indicates field power is present . OK LED indicates backplane power is present . |
One LED per point shows individual point ON/OFF state (logic side) . FLD PWR LED indicates field power is present . OK LED indicates backplane power is present . |
| Dimensions (W x H x D) | 110 mm (4 .3 in) x 66 .8 mm (2 .63 in) x 50 mm (1 .956 in), not including the height of the carrier or the mating connectors |
110 mm (4 .3 in) x 66 .8 mm (2 .63 in) x 50 mm (1 .956 in), not including the height of the carrier or the mating connectors |
110 mm (4 .3 in) x 66 .8 mm (2 .63 in) x 50 mm (1 .956 in), not including the height of the carrier or the mating connectors |
Discrete Output Modules
Discrete output modules send control signals to devices such as contactors, indicator lamps, and
interposing relays that can also have two states . Modules require a carrier base (IC200CHSxxx) .
