IC220PWR101 GE Power Terminal 120 VAC VAR 275 VAC IC220TBK204

Name: IC220PWR101 GE Power Terminal 120 VAC VAR 275 VAC IC220TBK204
Brand: Shenzhen Wisdomlong Technology CO.,LTD
SKU: IC220PWR101
Price: 10000.00 USD
Availability: InStock

Product Details:

Place of Origin:	USA
Brand Name:	GE
Model Number:	IC220PWR101

Detail Information

Place of Origin:

USA

Brand Name:

Model Number:

IC220PWR101

Brand:

Model:

IC220PWR101

Origin:

USA

Type:

Module

Highlight:

High Light

Highlight:

ewing machine servo motor

ac servo motor

Trading Information

Minimum Order Quantity:

Price:

negotiable

Packaging Details:

New in original box

Delivery Time:

5-8 work days

Payment Terms:

T/T

Supply Ability:

Product Description

IC220PWR101 GE Power Terminal 120 VAC VAR 275 VAC IC220TBK204

Power Terminals

Power Terminal modules supply power to the main circuit (UM) . In addition, this module can be
used to supply power for a segment circuit (Us) .

An I/O Network Interface Unit connects VersaPoint I/O modules to a host PLC or computer via a

variety of networks, which makes it easy to include VersaPoint I/O in PROFIBUS-DP, Ethernet or

DeviceNet installations . Together, the NIU is capable of handling up to 63 modules in one node .

	IC220PWR001	IC220PWR002	IC220PWR003	IC220PWR101	IC220PWR201
Product Name	Power Terminal 24 VDC	Power Terminal Fused 24 VDC	Power Terminal Fused with Diagnostics 24 VDC	Power Terminal 120 VAC	Power Terminal 230 VAC
Lifecycle Status	Active	Active	Active	Active	Active
Input Voltage	24 VDC	24 VDC	24 VDC	120 VAC	120 VAC
Input Voltage Range	19 .2 - 30 VDC	19 .2 - 30 VDC	19 .2 - 30 VDC	108 -135 VAC	12 -253 VAC
Maximum Current	8 Amps	8 Amps	6 .3 Amps	8 Amps	8 Amps
Overload/Short Circuit in Segment Circuit	No	Fuse	Fuse	No	No
Surge Voltage/Over Voltage	Yes, suppressor diode for voltage limitation	Yes, suppressor diode for voltage limitation	Yes, suppressor diode for voltage limitation	Yes, VAR 275 VAC	Yes, VAR 275 VAC
Polarity Reversal	Yes, diode connected in parallel as protection against polarity reversal	Yes, diode connected in parallel as protection against polarity reversal	Yes, diode connected in parallel as protection against polarity reversal	N/A	N/A
Current Consumption from Local Bus UL (mA)	N/A	N/A	25 mA, maximum	N/A	N/A
LED Indicators	24 VDC Voltage Present	24 VDC Voltage Present and Blown Fuse	Bus Diagnostics and Blown Fuse	120 VAC supply Present	230 VAC supply Present
Required Terminal Strip	(1) IC220TBK087 (Contains 10 strips)	(1) IC220TBK087 (Contains 10 strips)	(1) IC220TBK087 (Contains 10 strips)	(1) IC220TBK204	(1) IC220TBK204

IC220PWR101 GE Power Terminal 120 VAC VAR 275 VAC IC220TBK204 0

IC220PWR101 GE Power Terminal 120 VAC VAR 275 VAC IC220TBK204 1
