ABB System 800xA TU810V1 MTU Module Termination Unit 3BSE013230R1 Compact Terminal Block

Name: ABB System 800xA TU810V1 MTU Module Termination Unit 3BSE013230R1 Compact Terminal Block
Brand: Shenzhen Wisdomlong Technology CO.,LTD
SKU: TU810V1
Price: 100000.00 USD
Availability: InStock

Product Details:

Brand Name:	ABB
Certification:	CE
Model Number:	TU810V1

Detail Information

Brand Name:

ABB

Certification:

Model Number:

TU810V1

Product Name:

TERMINATION BASE

Model No.:

TU810V1

Article Number:

3BSE013230R1

Channels:

Connection:

Terminal Block

Voltage:

50V

Single/redundant I/O:

Single

Weight:

0.5kg

Highlight:

High Light

Highlight:

ethernet i o module

digital input output module

Trading Information

Minimum Order Quantity:

Price:

Packaging Details:

New Original Box

Delivery Time:

In Stock

Payment Terms:

T/T / Paypal

Supply Ability:

Product Description

ABB System 800xA TU810V1 MTU Module Termination Unit 3BSE013230R1 Compact Terminal Block

General Information

Article number	3BSE013230R1
Type	Compact
Connection	Terminal block
Channels	16
Voltage	50 V
Mounting	Both directions
Mounting detail	Horizontal 55 ºC (131 °F) Vertical 40 ºC (104 °F)
Use with I/O	AI810, AI815, AI820, AI830, AI830A, AI835, AI835A, AI845, AO810, AO810V2, AO815, AO820, AO845, AO845A, DI810, DI811, DI814, DI830, DI831, DI840, DI880, DI885, DO810, DO814, DO815, DO840, DO880, DP820, DP840
Process connections	2 x 2 Process power, 5 x 2 Process power (0 V)
Single/redundant I/O	Single

Description

The TU810/TU810V1 is a 16 channel 50 V compact module termination unit (MTU) for the S800 I/O. The MTU is a passive unit used for connection of the field wiring to the I/O modules. It also contains a part of the ModuleBus.

The MTU distributes the ModuleBus to the I/O module and to the next MTU. It also generates the correct address to the I/O module by shifting the outgoing position signals to the next MTU.

Two mechanical keys are used to configure the MTU for different types of I/O modules. This is only a mechanical configuration and it does not affect the functionality of the MTU or the I/O module. Each key has six positions, which gives a total number of 36 different configurations.

Dimensions

Height	186 mm (7.32”) including latch
Width	124 mm (4.88”)
Depth	47 mm (1.85”)
Weight (including base)	0.5 kg (1.1 lbs.)

Features and benefits

Compact installation of I/O modules using one-wire connections.
Up to 16 channels of field signals and process power connections.
Connections to ModuleBus and I/O modules.
Mechanical keying prevents insertion of the wrong I/O module.

Communications

Model No.	Protocol	Master or slave
CI801	PROFIBUS DP-V1	Slave
CI840A	PROFIBUS DP-V1	Slave
CI853	COMLI and MODBUS RTU	Master / Slave
CI854B	PROFIBUS DP-V1	Master
CI855	ABB's MasterBus 300	Master
CI856	ABB's S100 I/O	Master
CI857	ABB's INSUM	Master
CI858	ABB's DriveBus	Master
CI860	FOUNDATION Fieldbus HSE	Master / Slave
CI865	ABB's Satt I/O	Master
CI867	MODBUS TCP	Master / Slave
CI868	IEC 61850	Master / Slave
CI869	ABB's Advant Fieldbus 100	Slave
CI871	PROFINET IO	Master
CI873	EtherNet IP / DeviceNet	Master
TB820V2	ABB's Modulebus	Slave
TB825 (Multi Mode)	ABB's Modulebus	Slave
TB826 (Single Mode)	ABB's Modulebus	Slave
TB840A	ABB's Modulebus	Slave
TB842	ABB's Modulebus	Not Applicable
TU807	ABB's Modulebus	Not Applicable
TU840	ABB's Modulebus	Not Applicable
TU841	ABB's Modulebus	Not Applicable
TU846	ABB's Modulebus	Not Applicable
TU847	ABB's Modulebus	Not Applicable
TU848	ABB's Modulebus	Not Applicable
TU849	ABB's Modulebus	Not Applicable
