3BSE042240R3 PP825A ABB Control System Accessory Resistive Touch Panel HMI

I. Product Overview
The ABB PP825A 3BSE042240R3 is a high-performance 5.7-inch resistive touch panel that functions as a vital Human-Machine Interface (HMI) in industrial automation systems. Developed by ABB—a global pioneer in power and automation technologies—this touch panel is specifically engineered to enable seamless interaction between operators and industrial processes or machinery, serving as a critical link in modern automated workflows.

Featuring a CSTN-LCD display with a 320×240 pixel resolution, the PP825A 3BSE042240R3 delivers clear and vivid presentation of both graphical elements and textual information. This capability allows operators to effortlessly monitor a wide range of operational data, including process variables, equipment status, and alarm notifications. The panel’s resistive touch interface ensures intuitive control: operators can input commands, adjust parameters, and navigate across different control screens with simple touch gestures, eliminating complex operational procedures.

This user-friendly design not only reduces the learning curve for new operators but also enhances the efficiency of daily operations. As an integral part of ABB’s comprehensive HMI solution portfolio, the PP825A 3BSE042240R3 boasts strong adaptability, making it suitable for integration into diverse industrial control setups—from small-scale manufacturing units to large-scale industrial plants. It effectively bridges the gap between human operators and automated systems, guaranteeing smooth and efficient industrial operations.

II. Technical Specifications

• Product Model: PP825A 3BSE042240R3
• Manufacturer: ABB
• Product Type: Resistive Touch Panel (HMI)
• Display Type: CSTN-LCD
• Display Resolution: 320×240 pixels
• Display Size: 5.7 inches
• Touch Technology: Resistive
• Input Voltage: [Specify the voltage range, e.g., 24V DC (±10%)]
• Power Consumption: [Typical power consumption value, e.g., < 10 W]
• Operating Temperature: –20°C to +50°C (non-condensing)
• Storage Temperature: –40°C to +70°C
• Humidity Range: 5% – 95% (non-condensing)
• Dimensions (W×H×D): [e.g., 150mm × 100mm × 30mm] (approx.)
• Mounting Method: Panel-mount
• Communication Interfaces: List the supported interfaces, e.g., RS-232, RS-485, Ethernet
• Backlight Life: Specify the approximate backlight life, e.g., 50,000 hours
