Product Details:
Payment & Shipping Terms:
|
| Brand: | Yaskawa | Model Number: | SGMPS-02ACA61-E |
|---|---|---|---|
| Country Of Origin: | Japan | Type: | Servo Motor |
| Delivery Time: | 2-3days | Power - Rated: | 850w |
| Voltage - Rated: | 100, 200VAC | RPM: | 3000 RPM |
| Weight: | 0.705 Lb (319.78g) | ||
| Highlight: | SGMPS-02ACA61-E Industrial Servo Motor,200 W Industrial Servo Motor,Yaskawa SGMPS Servo Motor In Industry |
||
SGMPS-02ACA61-E Yaskawa Industrial Servo Motor SGMPS Series 200 W
Detailed description of SGMPS-02ACA61-E
Continuous time maintenance and heat resistance クラス B
Never resistance DC500 V and never resistance AC1500 V above 10 MΩ 1 sub division
Operating cycle temperature 0 ~ 40℃ protection mode fully closed self-cooling IP55(shaft through を except く)
Excitation mode Permanent magnet shape operating humidity 20 ~ 80%(dew しないこと)
Withdraw and pay け method フランジ type connection method straight knot
Speed reducing mechanism The direction of the actuator で load side から See て time counter り(CCW)に no instructions
Detailed description of SGMPS-02ACA61-E Yaskawa Industrial Servo Motor
| Type | Rotary Servo Motors Without Gears |
| Series | Sigma-3 SGMPS Series |
| Rated Output | 200 W |
| Voltage | 200 V |
| Serial Encoder | 17-bit Incremental |
| Rotation Speed | 3000 RPM - 6000 RPM |
| Specifications | Straight, Key, Tap |
| Options | No Option |
| Time Rating | Continuous |
| Thermal Class | Class B |
| Vibration | 15μm |
| Withstand Voltage | 1500VAC 1 min |
| Insulation Resistance | 500VDC, 10MΩ or more |
| Enclosure | Totally-enclosed, self-cooled |
| Ambient Temperature | 0 to 40ºC |
| Ambient Humidity | 20 to 80% (non-condensing) |
| Excitation | Permanent magnet |
| Drive Method | Direct drive |
| Mounting | Flange-mounted |
