Ambient Temperature Range
32 to 104 °F
-
Automation Option Cards
SM-APPS-LITE-V2, SM-APPS-PLUS, SM-REGISTER, SM-EZMOTION
-
Backup Option Cards
SMARTCARD
-
Communications Option Cards
SM-CAN, SM-CANOPEN, SM-DEVICENET, SM-ETHERCAT, SM-ETHERNET, SM-INTERBUS, SM-PROFIBUS-DP, SM-PROFINET, SM-SERCOS
-
Compatible Accessories
Backup, Communications, I/O, Feedback, Automation
-
Configurable Digital Inputs Outputs
3
-
Dynamic Braking
Dynamic Braking Transistor
-
Drive Supply Voltage
380/480 V ac
-
Enclosure Rating
IP 20
-
Encoder Connection
Standard
-
Overall Dimensions (Height x Width x Depth)
12.7 in x 2.4 in x 8.9 in
-
Feedback Option Cards
SM-ENCODER-OUT, SM-ENCODER-PLUS, SM-RESOLVER, SM-UNI-ENCODER
-
Minimum Ambient Temperature
32 °F
-
Feedback Type
Incremental Encoder, Absolute Encoder
-
Horsepower Rating Heavy Duty
1/2 hp
-
Maximum Ambient Temperature
104 °F
-
Horsepower Rating Normal Duty
1/2 hp
-
I/O Option Cards
SM-I/O-32, SM-I/O-120V, SM-I/O-24V, SM-I/O-LITE,SM-I/O-PELV, SM-I/O-PLUS, SM-I/O-TIMER
-
Input Frequency Rating
50/60 Hz
-
Keypad / Display
Option Keypad-SP0
-
Number of Safety Inputs - STO
1
-
Max Ambient Temperature
104 °F
-
Min Ambient Temperature
32 °F
-
Configurable Digital Inputs/Outputs
3
-
Motor Phase
3 ph
-
Mounting Type
Surface
-
Number Of Analog Inputs
3
-
Number Of Analog Outputs
2
-
Number Of Digital Inputs
3
-
Number Of Digital Outputs
1
-
Number Of Input Phases
3
-
Number Of Option Slots
2
-
Number of Relays
1
-
Number Of Safety Inputs Sto
1
-
Operating Temperature Range
+32 to +122 °F
-
Operation Mode
Open Loop Vector Control, V/Hz Control, Closed Loop Induction Motor Control, Regenerative Control, Servo Control, Rotor Flux Control
-
Output Current Heavy Duty
1.3 A
-
Output Current Normal Duty
1.3 A
-
Overall Depth
226 mm
-
Overall Dim Height Width Depth
12.7 in x 2.4 in x 8.9 in
-
Overall Height
322 mm
-
Overall Width
62 mm
-
PI / PID Controller
PID Controller
-
PLC Functions
Onboard PLC
-
Peak Current
2.3 A
-
Peak Current Heavy Duty
2.2 A
-
Peak Current Normal Duty
1.9 A
-
Pulse Train Input Capability
Yes
-
Pulse Train Output Capability
Yes
-
Remote Keypad
SM-KEYPAD-PLUS
-
Serial Communication Onboard
Modbus RTU
-
Serial Communication Options
CANOpen, DeviceNet, EtherNet/IP, Modbus TCP/IP, EtherCAT, PROFIBUS DP
-
Series
Unidrive SP
-
Standard Operating Temperature Range
32 to +104 °F
-
Standards Met
UL508C, EN 61800-5-1:2007, EN 61800-3:2004, EN 61000-6-2:2005, EN 61000-6-4:2007, EN 61000-3-2:2006, EN 61000-3-3:2008
-
Typical Application
Fans, Pumps, Conveyors, Compressors, Extruders, Winders, Hoists, Packaging, Printing, Cutting
-
Warranty
1 Years
-
Weight
4.6 lbs
