• Ambient Temperature Range
  32 to 104 °F
• Automation Option Cards
  SM-APPS-LITE-V2, SM-APPS-PLUS, SM-REGISTER, SM-EZMOTION
• Backup Option Cards
  SMARTCARD
• Communications Option Cards
  SM-CAN, SM-CANOPEN, SM-DEVICENET, SM-ETHERCAT, SM-ETHERNET, SM-INTERBUS, SM-PROFIBUS-DP, SM-PROFINET, SM-SERCOS
• Compatible Accessories
  Backup, Communications, I/O, Feedback, Automation
• Configurable Digital Inputs Outputs
  3
• Dynamic Braking
  Dynamic Braking Transistor
• Drive Supply Voltage
  380/480 V ac
• Enclosure Rating
  IP 20
• Encoder Connection
  Standard
• Overall Dimensions (Height x Width x Depth)
  12.7 in x 2.4 in x 8.9 in
• Feedback Option Cards
  SM-ENCODER-OUT, SM-ENCODER-PLUS, SM-RESOLVER, SM-UNI-ENCODER
• Minimum Ambient Temperature
  32 °F
• Feedback Type
  Incremental Encoder, Absolute Encoder
• Horsepower Rating Heavy Duty
  1/2 hp
• Maximum Ambient Temperature
  104 °F
• Horsepower Rating Normal Duty
  1/2 hp
• I/O Option Cards
  SM-I/O-32, SM-I/O-120V, SM-I/O-24V, SM-I/O-LITE,SM-I/O-PELV, SM-I/O-PLUS, SM-I/O-TIMER
• Input Frequency Rating
  50/60 Hz
• Keypad / Display
  Option Keypad-SP0
• Number of Safety Inputs - STO
  1
• Max Ambient Temperature
  104 °F
• Min Ambient Temperature
  32 °F
• Configurable Digital Inputs/Outputs
  3
• Motor Phase
  3 ph
• Mounting Type
  Surface
• Number Of Analog Inputs
  3
• Number Of Analog Outputs
  2
• Number Of Digital Inputs
  3
• Number Of Digital Outputs
  1
• Number Of Input Phases
  3
• Number Of Option Slots
  2
• Number of Relays
  1
• Number Of Safety Inputs Sto
  1
• Operating Temperature Range
  +32 to +122 °F
• Operation Mode
  Open Loop Vector Control, V/Hz Control, Closed Loop Induction Motor Control, Regenerative Control, Servo Control, Rotor Flux Control
• Output Current Heavy Duty
  1.3 A
• Output Current Normal Duty
  1.3 A
• Overall Depth
  226 mm
• Overall Dim Height Width Depth
  12.7 in x 2.4 in x 8.9 in
• Overall Height
  322 mm
• Overall Width
  62 mm
• PI / PID Controller
  PID Controller
• PLC Functions
  Onboard PLC
• Peak Current
  2.3 A
• Peak Current Heavy Duty
  2.2 A
• Peak Current Normal Duty
  1.9 A
• Pulse Train Input Capability
  Yes
• Pulse Train Output Capability
  Yes
• Remote Keypad
  SM-KEYPAD-PLUS
• Serial Communication Onboard
  Modbus RTU
• Serial Communication Options
  CANOpen, DeviceNet, EtherNet/IP, Modbus TCP/IP, EtherCAT, PROFIBUS DP
• Series
  Unidrive SP
• Standard Operating Temperature Range
  32 to +104 °F
• Standards Met
  UL508C, EN 61800-5-1:2007, EN 61800-3:2004, EN 61000-6-2:2005, EN 61000-6-4:2007, EN 61000-3-2:2006, EN 61000-3-3:2008
• Typical Application
  Fans, Pumps, Conveyors, Compressors, Extruders, Winders, Hoists, Packaging, Printing, Cutting
• Warranty
  1 Years
• Weight
  4.6 lbs
